Rangemaster Atlantic Kube Micro-Sheen Finish 1.0 Bowl Undermount Sink

Rangemaster Atlantic KUB18/ Details

The modern square waste and overflow cover, which quickens water draining, an attractive and important feature of the Atlantic Kube Kitchen-Sink series by Rangemaster. This under-mount, single-bowl is made from stainless steel and comes with a square basket strainer-waste kit for added convenience. Micro-sheen finished for better handling; it is covered with a 25-year manufacturers guarantee.

Available in 5 sizes - 210mm, 370mm, 430mm, 530mm, 730mm
Finish Micro-Sheen soft brush finish to the bowl and drainer
Single-bowl kitchen sink
Installation Under-Mount Features and Specification
Sizes Denotes: Length [Left to Right] x Width [Front to Back]
Download the Installation and Aftercare Guide, Cutout Template and Specification PDF file from the additional info section
Specification for 210mm
Overall Dimension: 210 x 430 x 140mm [Length x Width x Depth]
Main bowl Dimension -210 x 400 x 140mm [Length x Width x Depth]
Minimum base unit size required: 300mm [30cm]
Cutout size: 178 x 398mm [Length x Width]
Specification for 370mm
Overall Dimension of sink: 370 x 430mm [Length x Depth]
Main bowl size: 340 x 400 x 185mm [Length x Width x Depth]
Base unit required: Minimum 400mm [40cm]
Cutout size: 338 x 398mm [Length x Width]
Specification for 430mm
Overall Dimensions: 430 x 430 x 200mm [Length x Width x Depth]
Main bowl Dimension: 400 x 400 x 200mm [Length x Width x Depth]
Minimum base unit size required: 500mm [50cm]
Cutout size: 398 x 398mm [Length x Width]
Specification for 530mm
Overall Dimension of sink: 530 x 430mm [Length x Depth]
Bowl 1 Dimensions: 500 x 400 x 200mm [Length x Width x Depth]
Base unit required: Minimum 600mm [60cm]
Cutout size: 498 x 398mm [Length x Width]
Specification for 730mm
Overall Dimension of sink: 730 x 430mm [Length x Depth]
Main bowl size: 700 x 400 x 200mm [Length x Width x Depth]
Base unit required: Minimum 800mm [80cm]
Cutout size: 698 x 398mm [Length x Width]
Available Optional Products:
Disposal Unit
Waste Disposal Adapter

Info / Size (mm)

Sink
Length: 370 mm
Width: 430 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Micro-Sheen
⤷ Country of Origin
: UK
⤷ Installation/Style
: Undermount
⤷ Number of Bowls
: 1.0
⤷ Overall Length
: 210
⤷ Overall Length
: 370
⤷ Overall Width
: 430
⤷ Minimum Base Unit Size Required
: 300
⤷ Length of Main Bowl
: 340
⤷ Length of Main Bowl
: 210
⤷ Width of Main Bowl
: 400
⤷ Depth of Main Bowl
: 140

⤷ Depth of Main Bowl
: 200
⤷ Cut-Out Length
: 178
⤷ Cut-Out Width
: 398
⤷ Cut-Out Template PDF Supplied
: Yes
⤷ Material
: Stainless Steel
⤷ Gauge / Thickness
: 1.0
⤷ Compatible With Optional Waste Disposal Unit
: Yes
⤷ Waste Included
: Yes
⤷ Waste Type
: Basket Strainer
⤷ Waste Hole Size
: 90
⤷ Warranty/Guarantee
: 25 Years

Additional Info & Downloads

Download the Specification Details Pdf File Download the Cut-Out Template Pdf File Download the Installation Instruction / Aftercare Information Pdf File

Add-Ons

Waste Disposal Unit

Free your kitchen from unsightly and unhygienic organic household waste. This unit magnet motor reaches high speed in a split second. Whilst running water through the team, food waste is liquefied into fine particles & easily flushed through the pipework.

No Option Selected
OP-102664 - Economy 500 Waste Disposer + £122.56
OP-102665 - Standard 700 Waste Disposer + £182.04
OP-102666 - Continuous Feed 750 Waste Disposer + £310.97
OP-102667 - Heavy Duty 800 Waste Disposer + £340.72

Accessories

Related accessories or extra items are available as options. Please note: The image shown is for illustration purpose only.

OP-102584 - Square Waste Disposal Adapter + £100.90

Rangemaster Atlantic Kube Micro-Sheen Finish Stainless Steel 1.0B Undermount Sink

£205.86

RRP: ~~£373.02~~

STOCK AVAILABLITY: 10 Working Days Approx

QS Supplies

1 Features Included In This Product Explained

Stainless Steel Material

Stainless Steel is an iron alloy with anti-rust and anti-corrosive properties, unlike iron. Along with other metal alloys, it contains a minimum of 10.5% of chromium and less than 1.2% of carbon. This robust, hygienic, hard-wearing base material is popular in the construction of bathroom products.
