Reina Colona 600mm High Horizontal 2 Column White Radiator

Reina Colona 2/C613 Details

Never sacrifice the look of your space for its warmth when you can have the Reina Colona High Horizontal Radiator, a heating appliance that gives you the best of both worlds. The radiator is fashioned out of high quality steel that won't easily show signs of wear and tear, even with frequent use. The finish is a neutral white to make it easy to incorporate into your living space with any colour scheme. The unit is suitable for central, electric, dual fuel heating systems.

Key Features

✔Brackets for radiator included
✔Manufactured using steel material
✔Supplied with Air vent and End plug
✔Five years guarantee against manufacturing defects
✔Choice of different finishes available - White and Laquer [Optional]

Available in different widths: 605mm, 785mm, 1010mm and 1190mm - [Optional]
Available variants: Central heating, Dual fuel and Electric - [Optional]
Choice of heating element available - [Optional]
Horizontal 2-column radiator
It comes in a white finish
Height: 600mm (60cm)
Wall to pipe centres: 66mm (6.6cm)
Distance from wall: 98mm (9.8cm)
EN 442 Compliant product
Heat output is measured at Delta 70°C
The image shown is for illustration purposes only
Insertable feet for radiator - [Optional]
For Central Heating And Dual fuel, Radiator valves are highly recommended
Refer to Compatible Valves available in the product
For the Dual Fuel and Electric model, Heating Elements are highly recommended in combination with T-Piece
For Electric models, Optional Liquid Filling is required with the heating element
For more details, please refer to the Product Variations Info and MFC Code table given below
Download the Heating Element Manual Instructions and Details PDF File from the Additional Info Section
The valves shown in the image are not included

Please Note: The appropriate wattage of the element if selected will be decided by the manufacturer, once the order is placed.

Radiator Calculator

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Colona
⤷ Colour
: White
⤷ Shape
: Curved
⤷ Country of Origin
: Turkey
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Steel
⤷ Installation Type
: Floor Standing
⤷ Width
: 605
⤷ Height
: 600
⤷ Orientation
: Horizontal
⤷ Compliance/Approvals/Standard
: EN 442
⤷ Barcode
: 5081304262313

⤷ BTU Output
: 3022
⤷ Watts
: 8866
⤷ No. Of Bars
: 13
⤷ Tapping / Pipe Centres
: 605
⤷ Valves Included
: Sold Separately
⤷ Fuel Type
: Central Heating | Dual Fuel | Electric
⤷ Wall to Centre of Inlet
: 66
⤷ Heating Element Included
: Sold Separately
⤷ Element Type
: Standard | Thermostatic
⤷ Brackets Included
: Yes
⤷ No. of Columns
: 2

Additional Info & Downloads

Download the Heating Element Manual Instructions Pdf File Download the Details Of Heating Elements Pdf File

Technical Images

Reina Colona 600mm High Horizontal 2 Column White Radiator

£156.19

RRP: ~~£251.92~~

IN-STOCK

Delivery in 4 Working Days Approx.

QS Supplies

Product Variations Info & MFC Code

Width	605mm	785mm	1010mm	1190mm
Finish	White	White	White	White
Tube Qty	13	17	22	26
Pipe Centres	605	785	1010	1190
Wall To Pipe Centres	66	66	66	66
Wall Distance	98	98	98	98
Fuel Type	Central/Electric/Duel	Central/Electric/Duel	Central/Electric/Duel	Central/Electric/Duel
Watts - Delta-70	886	1159	1499	1772
BTU - Delta-70	3022	3951	5112	6043
BTU - Delta-60	2477	3239	4190	4953
BTU - Delta-50	1950	2549	3298	3899
BTU - Delta-45	1698	2220	2872	3395
BTU - Delta-40	1467	1918	2482	2933
BTU - Delta-35	1228	1606	2078	2457
BTU - Delta-30	997	1304	1687	1994
BTU - Delta-25	388	508	657	777
MFC	2/C613	2/C617	2/C622	2/C626

Width	605mm	785mm	1010mm	1190mm
Finish	Laquer - Raw Material	Laquer - Raw Material	Laquer - Raw Material	Laquer - Raw Material
Tube Qty	13	17	22	26
Pipe Centres	605	785	1010	1190
Wall To Pipe Centres	66	66	66	66
Wall Distance	98	98	98	98
Fuel Type	Central/Electric/Duel	Central/Electric/Duel	Central/Electric/Duel	Central/Electric/Duel
Watts - Delta-70	886	1159	1499	1772
BTU - Delta-70	3022	3951	5112	6043
BTU - Delta-60	2477	3239	4190	4953
BTU - Delta-50	1950	2549	3298	3899
BTU - Delta-45	1698	2220	2872	3395
BTU - Delta-40	1467	1918	2482	2933
BTU - Delta-35	1228	1606	2078	2457
BTU - Delta-30	997	1304	1687	1994
BTU - Delta-25	388	508	657	777
MFC	2/C613L	2/C617L	2/C622L	2/C626L

2 Features Included In This Product Explained

Optional: Radiator Valve

Radiator valves help control how much hot water enters and leave it, and the flow of water controls how much heat the radiator generates. These are usually found at the radiator's bottom left, and right corners, where the water pipes enter and exit, or can also be present at the bottom near the centre.
Read more...

Optional: Dual Fuel

These radiators or towel warmers can run on a conventional gas-powered central heating system or via your mains electrical supply. You can choose whether or not you want your radiator or towel warmer to come on independently of your central heating system, which is especially useful in summer. These radiators are compatible with heating and hot water, whether the system is open (direct) or closed (indirect).
