Duravit Starck 1 White Close Coupled Toilet With Cistern And Seat

Duravit Starck 1 0233090064 Details

The Starck 1 Close Coupled Toilet with Cistern and Toilet Seat displays ultra-modern lines and a perfect white finish that makes for a stunning look. Designed with smooth curves to create an ambience of splendour, the Pan is sure to fascinate you with its charismatic appeal. Close-coupled toilet pack includes WC Pan, Cistern and Toilet Seat and Cover.

The sturdy and robust bathroom necessity is suitable for Commercial, Domestic, Hotel and Leisure establishments. Suitable brassware is available separately. Easy to install and backed by the manufacturer's 5-year warranty, this toilet is offered at QS Supplies for a super-discounted price, so it's now easier to update your bathroom.

Close-coupled toilet pack
Pack includes: WC pan, cistern and toilet seat and cover
Overall dimension: 415mm x 1045mm [Width x Height]
Projection from wall: 640mm
Refer to the technical image for detailed technical dimensions
Download the PDF file for installation instructions from the Additional Info section
Five years of warranty against manufacturing defects
WC Pan:
Manufacturing code: 0233090064
Dimension: 415mm x 385mm [Width x Height]
Projection: 640mm
Compatible with 4.5-litre flush
Vario connector set for a horizontal and vertical outlet [Optional]
Vario connecting bend for a vertical outlet [Optional]
Cistern:
Manufacturing code: 8727150005
Size: 390mm x 125mm x 650mm [Width x Depth x Height]
Suitable with concealed left supply
Chrome finish push button PURO
Compatible with 6-litre flush
Toilet Seat and Cover:
Manufacturing code: 0065880099
It comes with a hinge shaft and stainless steel hinge plate

Info / Size (mm)

Toilet
Width: 415 mm
Projection: 640 mm
Height: 1045 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Starck 1
⤷ Colour
: White
⤷ Country of Origin
: Germany
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Ceramic
⤷ Theme
: Modern
⤷ Installation Type
: Floor Mounted
⤷ Water Saving
: Yes
⤷ Pan Width
: 415
⤷ Pan Height
: 385
⤷ Toilet Overall Height
: 1045
⤷ Projection (Depth)
: 640
⤷ Cistern Included
: Yes
⤷ Cistern Width
: 390

⤷ Cistern Height
: 650
⤷ Flush Type
: Dual
⤷ Flush Mechanism
: Push Button
⤷ Cistern Lever Or Button Placement
: Top
⤷ Configuration
: Pan With Cistern And Seat
⤷ Seat Included
: Yes
⤷ Seat Type
: Soft Close
⤷ Seat Finish
: White
⤷ Barcode
: 4021530000000
⤷ Bowl Shape
: Round
⤷ Product Type
: Close Coupled WC
⤷ Outlet Diameter
: 102
⤷ Base to centre of outlet
: 180

Additional Info & Downloads

Download the Installation Instruction of Pan Pdf File Download the Installation instruction of Cistern Pdf File

Duravit Starck 1 White Close Coupled Toilet With Cistern And Seat

£1487.12

RRP: ~~£2341.20~~

STOCK AVAILABLITY: 7 Working Days Approx

QS Supplies

4 Features Included In This Product Explained

Soft-Close Seat

Soft-closing seats are a new alternative to classic seats. Their modern design hinges allow them to close slowly and gently.

Horizontal Outlet

When the pan has piping at the back, inside the wall, it is called a horizontal outlet toilet or pan. As the cisterns are concealed or placed against the wall, most plumbing is hidden out of sight.

Push-Button Flush Valve Cistern

Toilets with push-button flush valves are usually dual-flush toilets. One button triggers a liquid, and the other is for solid flushes. Additionally, since these valves are smaller than levers, they use less water than traditional toilets.

Vertical Outlet

It is a toilet where the plumbing exits through the floor. In certain scenarios, these toilets may need to be installed a few inches higher than the surrounding floor to accommodate the plumbing.
