Burlington Chaplin Chrome Traditional Radiator 542 x 1142mm

Burlington Chaplin R12 CHR Details

Bring some hot style and a healthy touch of heat to your home with the Traditional Radiator from the popular Chaplin collection by Burlington. The premium-grade steel construction makes it a sturdy addition to your interiors. It carries a lovely contemporary design which is splendidly emphasised with a bright chrome finish. The fashionably functional creation exudes abundant warmth to envelope your condos and estates in inviting heat. Designed for use with central heating systems, it requires an operating water pressure of up to 8 bar. It is backed by ten years of guarantee from the manufacturer.

It comes in a chrome finish
Size [mm]: 542mm x 136mm x 1142mm [Width x Depth x Height]
Size [cm]: 54.2cm x 13.6cm x 114.2cm [Width x Depth x Height]
Heat output at Delta 50°C: BTU - 1024, Watts - 235
Distance from wall to the rail: 94mm (9.4cm)
Plumbing pipe centres: 234mm (23.4cm)
Tube diameter: 32mm (3.2cm)
Traditional design
Supplied with all brackets and fixings
Maximum working temperature: 70°C
Weight: 10 kg
Valves and electric heating elements shown in the image are not included
Fill the radiator approximately 90% [3.1 litres] with a water mixture if the radiator is to be used for electric heating only [not connected to a central heating system]
Angled Valve and 150W Summer Electric Heating Kit Optional [See Option]
Compatible 200W Stainless steel electric element [See Option]
The manufacturing code of this product is R12 CHR
For complete size detail, refer to the line drawing
Download the Installation Instruction PDF File from the Additional Info Section

Radiator Calculator

Info / Size (mm)

Towel Rail
Width: 542 mm
Height: 1142 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Chaplin
⤷ Colour
: Chrome
⤷ Weight in kg
: 10
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Steel
⤷ Installation Type
: Wall Mounted
⤷ Projection (Depth)
: 136
⤷ Width
: 542
⤷ Height
: 1142
⤷ Fixings included
: Yes
⤷ Orientation
: Vertical
⤷ Compliance/Approvals/Standard
: BS EN442-1:2003, BS EN442-2:2003, BS EN248:2002

⤷ Barcode
: 5055806005549
⤷ BTU Output
: 50°C: 1024
⤷ Watts
: 50°C: 235
⤷ Tapping / Pipe Centres
: 234
⤷ Valves Included
: Sold Separately
⤷ Fuel Type
: Electric
⤷ Special Finishes Available
: No
⤷ Wall to Centre of Inlet
: 110
⤷ Tube Diameter
: 32
⤷ Heating Element Included
: Sold Separately
⤷ Pressure Tested (bars)
: 8 bar

Additional Info & Downloads

Download the Installation Instruction Pdf File

Add-Ons

Radiator Valves

The valves are chrome-plated and are polished extravagantly. The body and handle both are made from the best quality brass. It also has an appealing traditional look.

No Option Selected
OP-33621 - Pair of Angled Valves + £39.67

Summer Electric Heating Kit

This Burlington Summer Electric Kit is chrome-plated and traditionally styled. The tubular body is made from the best quality stainless steel and has immense resistance inside.

No Option Selected
OP-197914 - 200W Stainless Steel Electric Element + £80.39

Burlington Chaplin Chrome Traditional Radiator 542 x 1142mm

£476.78

STOCK AVAILABLITY: 4 Working Days Approx

QS Supplies

2 Features Included In This Product Explained

Electric Only

Electric Only options are independent units requiring a fused spur electric connection. These radiators and towel warmers are powered by the mains electrical supply instead of a gas boiler. You can turn on each radiator or towel warmer as and when you need them.
Read more...

BTU Output

It is the short form of a British thermal unit (BTU or Btu) and is defined as the amount of heat required to raise the temperature of one pound of water by one degree Fahrenheit. It is a standard unit against which radiator efficiency is measured.
Read more...

Questions & Answers

Submit Your Questions 1 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Sophie Asked :
Hello, I am interested in your Burlington Chaplin Wall-Mounted Towel Radiator. I would like to have it installed for electric use only and would be grateful if you could let me know what items I will need to purchase with it so that it can be used as such. I would also be grateful if you could let me know if you have any electric cable sheathes to go over the power cable to the element.

Answered By QS Team

The R12 CHR Chaplin radiator can be used with an electric element BUR9 (200W Stainless Steel Electric Element ), which is option in the "Customise Your Product" section. Unfortunately, we haven't got any covering sheaths.
