Heritage Glastonbury Recessed Thermostatic Shower Valve With Fixed Head Kit

Heritage Glastonbury SGDUAL01 Details

The Heritage Glastonbury Recessed Thermostatic Valve with its traditional design and exquisite craftsmanship adds vintage charm to any bathroom. By obscuring working parts, this concealed set offers a trim yet traditional aesthetic that is suited to the interior themed around classic design. Available in your choice of chrome, vintage gold or brushed nickel finish, this valve features two separate shower controls.

The period-style handles, inlaid with white detailing offer smooth and efficient control over water flow and temperature. It incorporates thermostatic technology to shut off the hot water feed should the cold inlet fail, preventing scalding and ensuring a safe, comfortable showering experience. The accompanying fixed shower head in a bell-shaped form with a fixed arm helps to set up a good-looking and functional shower space.

Includes thermostatic valve, fixed head and arm
Premium large 6-inch head and 350mm [35cm] wall-mounted arm
Traditional design
Features:
Features ceramic disc and one outlet
Dual control - separate control for flow and temperature
Concealed wall installation [requires only 35mm [3.5cm] cavity depth]
Size Of Faceplate [mm]: 185mm x 140mm x 245mm [Width x Height x Depth]
Size Of Faceplate [cm]: 18.5cm x 14cm x 24.5cm [Width x Height x Depth]
Inlet connection: 15mm [1.5cm] compression elbows with 150mm [15cm] centres
Outlet connection: G 1/2 inch
It is designed in the UK by expert engineers, so they can operate effectively even at low pressure, making them suitable for all water systems
The minimum water pressure Recommended for smooth working is 0.2 bar [LP-Low Pressure], and the maximum is 5.0 bar
Plumbing system suitability: all - ideally balanced
Refer to the technical image for more technical details
Download the installation instruction PDF file from the additional info section

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Brass
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: 3/4” Ceramic Disc Valve - 1/4 turn
⤷ Inlet Centres
: 150
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Flow Rates (l/min)
: 0.2 Bar - 6.8, 0.5 Bar - 10.8, 1 Bar - 15.3, 2 Bars - 21.6, 3 Bars - 26.5, 5 Bars - 34.2
⤷ Configuration
: Valve, Fixed Head And Arm

⤷ Temperature Control
: Thermostatic
⤷ Anti-Scald
: Yes
⤷ Product Type
: Shower Set
⤷ Plumbing System Compatibility
: All
⤷ Showerhead Type
: Fixed
⤷ Auto shutdown if hot or cold supplies fail
: Yes
⤷ Valve Size
: W 185mm x H 245mm
⤷ Shower Head Included
: Yes
⤷ Shower Head Size
: 6 Inch

Additional Info & Downloads

Download the Installation Instruction for Shower Arm Pdf File Download the Installation Instruction for Shower Head Pdf File Download the Installation Instruction for Shower Valve Pdf File Download the Product Data Sheet Pdf File

Heritage Glastonbury Recessed Thermostatic Shower Valve With Fixed Head Kit

£444.37

RRP: ~~£751.00~~

STOCK AVAILABLITY: 6 Working Days Approx

QS Supplies

4 Features Included In This Product Explained

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

1-Outlet

One outlet in a shower system means that hot and cold water flows from a single opening.

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...
