Heritage Glastonbury Recessed Thermostatic Shower Valve With Flexible Riser Kit And Head

Heritage Glastonbury SGDUAL03 Details

The Heritage Glastonbury Recessed Thermostatic Valve features a classic design which lends a degree of class and sophistication to the bathroom. With separate vintage cross-headed controls operated with ceramic cartridge technology, this unit gives the user easy control over water flow and temperature. The finish with white detailing on the handset and controls enhances the traditional design. It includes an automatic cut-off should there be a loss of cold water.

Attached to a wall mounting arm, the fixed, large, and round Shower Rose ensures a thorough shower each time. Featuring a superb spray and a generous flex, the separate handset is the ideal piece for convenient rinsing facilities. The slide rail ensures you can rest your shower head at the required height.

Traditional design
Valve Features:
Ceramic disc and two outlets with integrated diverter which means that you can choose both a fixed head and a handset
Concealed wall installation [requires only 35mm [3.5cm] cavity depth]
Size Of Faceplate [mm]: 185mm x 245mm [Width x Height]
Size Of Faceplate [cm]: 18.5cm x 24.5cm [Width x Height]
Inlet connection: 15mm [1.5cm] compression elbows with 150mm [15cm] centres
Outlet connection: G 1/2 inch
Designed in the UK by expert engineers, so they can operate effectively even at low pressure, making them suitable for all water systems
Flexible inlet elbows so that they can be adjusted to fit existing pipework if required
The minimum water pressure Recommended for smooth working is 0.2 bar [LP-Low Pressure], and the maximum is 5.0 bar
Suitable for both low and high-water pressure systems
Shower Specifications:
The flexible kit consists of the slide rail, handset, hose, and outlet
Single-function premium handset with clean rub nozzles
Riser rail height: 710mm [71cm]
Wall-mounted 350mm [35cm] arm and fixed large round rose
Head of a diameter: 6 inches [155mm] [15.5cm]
Plumbing system suitability: all - ideally balanced
The image shown is for illustration purposes only
For complete size details, please refer to the technical drawing
Download the Installation Instruction Manual PDF File from the Additional Info Section

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Brass
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Concealed
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Hose Included
: Yes
⤷ Hose Length
: 1500
⤷ Spray Setting
: 1
⤷ Configuration
: Valve, Slide Rail, Fixed Head And Handset Kit
⤷ Temperature Control
: Thermostatic

⤷ Anti-Scald
: Yes
⤷ Product Type
: Shower Set
⤷ Plumbing System Compatibility
: All
⤷ Showerhead Type
: 6” Shower Rose
⤷ Separate temperature and power controls
: Yes
⤷ Handset Included
: Yes
⤷ Valve Size
: W 185mm x H 245mm
⤷ Shower Head Included
: Yes
⤷ Shower Head Size
: 6 Inch (155)
⤷ Rail Length
: 625

Additional Info & Downloads

Download the Installation Instruction for Shower Arm Pdf File Download the Installation Instruction for Shower Head Pdf File Download the Installation Instruction for Shower Kit Pdf File Download the Installation Instruction for Shower Valve Pdf File Download the Product Data Sheet Pdf File

Heritage Glastonbury Recessed Thermostatic Shower Valve With Flexible Riser Kit And Head

£523.28

RRP: ~~£885.00~~

IN-STOCK

Delivery in 4 Working Days Approx.

QS Supplies

4 Features Included In This Product Explained

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

Easy Clean Nozzles

Shower heads and handsets can be easily cleaned with a damp cloth, preventing limescale build-up.

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...
