Bristan Prism Thermostatic Exposed Sequential Valve With Adjustable Chrome Riser Kit

Bristan Prism PM2 SQSHXAR C Details

Get to ready to take your showering moments to a delightfully refreshing level when you bring home this elegantly appealing Bristan Prism Thermostatic Exposed Sequential Valve With Adjustable Riser Kit, which consists of riser rail with an adjustable fixing bracket, rub-clean handset and a hose. The factory-fitted regulators ensure that this shower consumes less water while giving you the same showering experience and ensures low water bills. Suitable for low and high water pressure system, this unit comes with adjustable inlet centres for facilitating usage of existing pipework and is supported by five years of manufacturer guarantee.

The manufacturing code of this product is: PM2 SQSHXAR C
It comes in an attractive chrome finish
No of controls: 1
Shower type: exposed valve
Shower head type: multi-function handset
Maximum hot water supply temperature: 65°C
Dynamic pressure range: 5 bar
Maximum static pressure: 10 bar
Suitable for all plumbing conditions
Requires a minimum of 0.1 bar to a maximum of 5.0 bar of water pressure
Flow rate: (l/min @ 3 bar) 13.4
Connection inlet: 15mm compression
Connection outlet: G 1/2 inch
Easy replacement with adjustable inlets so you can use on existing pipework centres between 136mm (13.6cm) and 158mm (15.8cm)
Thermostatic cartridge with preset temperature stop at 42°C
Refer technical diagram for technical dimensions
Download the Installation Instruction PDF File From The Additional Info Section

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 5 Years
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Exposed
⤷ Inlet Centres
: 136-158
⤷ Minimum Operating Pressure (Bar)
: 0.1

⤷ Hose Included
: Yes
⤷ Configuration
: Valve With Rigid Riser, Handset and Hose
⤷ Temperature Control
: Thermostatic
⤷ Handset Included
: Yes
⤷ Valve Size
: Depth - 111
⤷ Rail Length
: 650

Additional Info & Downloads

Download the Installation instruction Pdf File

Bristan Prism Thermostatic Exposed Sequential Valve With Adjustable Chrome Riser Kit

£260.53

RRP: ~~£519.00~~

IN-STOCK

Delivery in 4 Working Days Approx.

QS Supplies

9 Features Included In This Product Explained

Family Safe

This feature corresponds with the Thermostatic mechanism and automatic safety stops, preventing running water from getting either too hot or too cold.

Decor Smart

In an attempt to keep your decor as neat as before, the unit has a design that will easily fit into the existing holes and fixings as your old shower.

Rub Clean

Any limescale deposits can simply be wiped clean with a clean cloth - no need to scrub or use harsh cleaners.

Luminance Chrome

It is a hard-wearing chrome plating which is salt-tested and scratch-proof for durable, long-lasting use.

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws.
Read more...

1-Outlet

One outlet in a shower system means that hot and cold water flows from a single opening.

Drenching

Drenching in Bristan showers means these showers soak you thoroughly, giving you the most indulgent showering experience.

Sequential Control In Showers

Sequential Control lets you turn the shower on and off and regulate the temperature by turning the same knob. The built-in integral check valves and strainers make it easy to use. The first movement of the knob turns the shower to the cold position, and any subsequent anti-clockwise movement increases the temperature to a set maximum.

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...
