Bristan Renaissance Kitchen Sink Mixer Tap With Easyfit Base

Bristan Renaissance RS SNK EF C Details

From the chic Renaissance range of Bristan, comes this sleek Kitchen Sink Mixer Tap for helping you finish your washing and cleaning chores in minimum time. This unit is manufactured from high quality brass for delivering excellent performance. It works with all plumbing systems and is suitable for a low water pressure system. This unit comes in an attractive finish for imparting a designer appeal to your bathroom and is available in 3 finish options. A 10-year manufacturer guarantee against any manufacturing faults accompanies this unit. Suitable to use with all types of kitchen sinks.

Pack include: An Allen key, isolation valves, Top Fix Easyfit base, Easyfit tool and flexi tails
Deck mounted installation
Flow type: Single
Handle type: lever handles
Number of tap holes: 1
Connection inlet: 1/2 inch BSP female flexible tails
Connection outlet: Anti-splash
Valve type: 1/2 Inch ceramic disc valve - 1/4 turn
Isolation included: Yes
Suitable for all plumbing systems
Metal fixing nut for added durability
Size [mm]: 150mm x 230mm x 365mm [Width x Depth x Height]
Size [cm]: 15cm x 23cm x 36.5cm [Width x Depth x Height]
Base to spout: 230mm - (23cm)
Centre of the inlet to centre of outlet: 185mm - (18.5cm)
Maximum hot water supply temperature: 65°C
Maximum static pressure: 10 bar
High-quality metal fixings for security and durability
Suitable for low and high water pressure systems
Required minimum 0.4 bar to maximum 5.0 bar water pressure
Long life and easy to use 1/4 turn ceramic disc valves
Two supplied isolation valves and flexi tails mean you can connect to the water supply at this point and isolate the base
Push the tap onto the base and secure it into position with the supplied Easyfit tool and screws
Drop and twist the top fix base into the tap hole from above, and lock it into place with the Allen key provided
Unique patented top fix design for simple installation from above the sink
Download the Installation Instruction PDF File From The Additional Info Section
Refer to the technical diagram for complete technical dimensions

Info / Size (mm)

Tap
Pipe Centre: 190 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Lifting/Tilting
⤷ Handle Position
: Left & Right
⤷ Range
: Renaissance
⤷ Tap Body Shape
: Round
⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 10 Years
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 1
⤷ Valve/Cartridge Type
: Ceramic Disc Valve
⤷ Spout Swivel
: Yes

⤷ Base To Spout
: 230
⤷ Spout Reach
: 185
⤷ Overall Height
: 365
⤷ Width
: 150
⤷ Minimum Operating Pressure (Bar)
: 0.4
⤷ Flow Rates (l/min)
: 14.1 Litre/Min @0.4 bar
⤷ Handle Style
: Lever
⤷ WRAS Approved
: Yes
⤷ Barcode
: 5014868034737
⤷ Product Type
: Sink Mixer Tap
⤷ Tails
: Flexible Tails

Additional Info & Downloads

Download the Installation Instruction Pdf File

Videos

Video of Bristan EasyFit Kitchen Taps

Bristan Renaissance Kitchen Sink Mixer Tap With Easyfit Base

£148.00

RRP: ~~£293.00~~

IN-STOCK

Delivery in 4 Working Days Approx.

QS Supplies

9 Features Included In This Product Explained

Luminance Chrome

It is a hard-wearing chrome plating which is salt-tested and scratch-proof for durable, long-lasting use.

Precise Glide

It comes incorporated with ceramic cartridges for long life with precise control for smooth, leak-free use.

Quick Change

The product can be simply removed and another one fixed in its place. All you need to do is turn off the water supply.

Swivel-Spout

The respective apparatus is engineered to move sideways or at certain angles, which helps the spout cover a greater area than would be possible in a fixed position.

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Flexible Tail Pipes

Flexible Tails, or "Flexi" Tails, are one of the easiest methods to connect the plumbing pipework to the tap fitting. Mixers generally have two tails, one for the hot water supply and the other for the cold. These tailpipes consist of rubber inside a braided metal and come in many sizes.

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws.
Read more...

Easyfit

Step1: Fitting the Base The first step is to slot the base of the tap into the sink. For this, detach the plain barrel from the EasyFit Base. Unscrew the fitting and push it through the hole in the sink or work surface. It must be in the central position, indicated by the word FRONT facing forward. Now tighten the fitting to the surface with a hex key, and replace the plain barrel. Step 2: Fitting the Tails Next, you need to connect the integral flexible tails to the hot and cold water sources after you have closed the built-in valves. Step 3: Fitting the Tap Body Push and secure the tap body to the base using grub screws, which are present on either side of the tap body. The grub screws must be tightened using the hex key.
