Aqualisa Midas 110 Chrome Thermostatic Bar Shower Mixer Valve With Slide Rail Kit

Aqualisa Midas MD110S Details

Aqualisa Midas 110 Thermostatic Bar Shower Mixer Valve With Slide Rail Kit is a fine assortment of the slide rail, 1.25m hose, Harmony handset and bar shower mixer valve. Suitable for all water systems, this solid construction is made out of brass. Slide Rail Kit offers adjustable height slider with retrofit brackets while handset comes with 4 spray patterns, anti-twist hose connector and Gel hose hanger with internal thermostat complete the picture.

The manufacturing code is MD110S
Includes slide rail, 1.25m [125cm] hose, Harmony handset and bar shower mixer valve
It comes in a chrome finish
Suitable for all water systems
Slide Rail Kit:
Adjustable height slider with retrofit brackets
Height is 565mm (56.5cm)
Easy clean handset nozzles
Anti-twist hose connector
Gel hose hanger
Valve:
Feature wax-stat technology
Size [mm]: 267mm x 87mm [Width x Depth]
Size [cm]: 26.7cm x 8.7cm [Width x Depth]
Inlet centres are 150mm (15cm)
The minimum water pressure recommended for smooth working is 0.1 bar [LP-Low Pressure], and the maximum static is 10.0 bar [HP-High Pressure]
Supply Temperature: 5 - 20°C Cold Supply and 55 - 65°C Hot Supply
Optional Products: Bar Valve Fixing Kit and Concealed Easy Fit Fixing Bracket

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Country of Origin
: UK
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Brass Valve
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Bar
⤷ Inlet Centres
: 150
⤷ Minimum Operating Pressure (Bar)
: 0.1
⤷ Hose Included
: Yes
⤷ Hose Length
: 1250

⤷ Spray Setting
: 4
⤷ Temperature Control
: Thermostatic
⤷ Product Type
: Shower Set
⤷ Plumbing System Compatibility
: All
⤷ Separate temperature and power controls
: Yes
⤷ Handset Included
: Yes
⤷ Spray Patterns (Shower Handset)
: Inner, Outer, Middle, ECO
⤷ Valve Size
: Width 287 x Depth 105
⤷ Rail Length
: 865

Additional Info & Downloads

Download the Fitting Instructions Pdf File

Aqualisa Midas 110 Chrome Thermostatic Bar Shower Mixer Valve With Slide Rail Kit

£243.01

RRP: ~~£366.43~~

IN-STOCK

Delivery in 4 Working Days Approx.

QS Supplies

3 Features Included In This Product Explained

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

Easy Clean Nozzles

Shower heads and handsets can be easily cleaned with a damp cloth, preventing limescale build-up.

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...
