IMEX Wyndham Traditional Low Level White WC Set

IMEX Wyndham CF10142 Details

Give your essential bathroom moments a delightfully comfortable twist with this IMEX Wyndham Traditional Low Lever WC Set. This unit includes high-level WC pan, cistern and chrome flush pipe kit with ornate brackets. The pan and cistern are finished in pristine white for giving your bathroom an appealing look. This unit comes with 25 years of guarantee for ceramic and 3 years of guarantee for internal working parts from the manufacturer against any manufacturing defects. This unit is also available in Low-Level WC Set option.

Includes low-level WC pan with cistern, chrome flush pipe kit and ornate brackets
Size [mm]: 370mm x 525mm x 400mm [Width x Depth x Height]
Size [cm]: 37cm x 52.5cm x 40cm [Width x Depth x Height]
Pan and cistern in white finish
Manufacturing codes are CF10142, T10142LLN, PELLFPP
Crafted using ceramic [precise combination of over 17 components, perfected over many years of manufacture]
Optional Product:
Toilet Seat And Cover
The seat and cover shown in the image are not included - sold separately

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: White
⤷ Weight in kg
: 42
⤷ Warranty/Guarantee
: 25 Years
⤷ Material
: Ceramic
⤷ Theme
: Traditional
⤷ Installation Type
: Floor Mounted
⤷ Pan Width
: 370
⤷ Pan Height
: 400
⤷ Projection (Depth)
: 525
⤷ Cistern Included
: Yes
⤷ Cistern Width
: 520

⤷ Cistern Type
: Low Level
⤷ Cistern Height
: 400
⤷ Flush Mechanism
: Lever
⤷ Cistern Lever Or Button Placement
: Left
⤷ Configuration
: Two Piece
⤷ Seat Included
: Sold Separately
⤷ Cistern Depth (projection)
: 177
⤷ Seat Post Hole Centers
: 155
⤷ Front Of Bowl To Centre Of Seat Holes
: 435
⤷ Outlet Diameter
: 100
⤷ Base to centre of outlet
: 185

Additional Info & Downloads

Download the Installation Guide Pdf File Download the Aftercare Guide Pdf File

IMEX Wyndham Traditional Low Level White WC Set

£314.50

RRP: ~~£580.00~~

STOCK AVAILABLITY: 4 Working Days Approx

QS Supplies

Other Sizes / Finishes

Other Sizes / Finishes / Variations Available.

QS Code	Finish	Size / Difference	MFC Code
QS-V80414	-	High Level WC Set	CF10142\|T10142HLN\|PEHLFPP

Back to QS-V80415 / MFC Code: CF10142|T10142LLN|PELLFPP

Questions & Answers

Submit Your Questions 1 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

J.jarman Asked :
What is the total height of the assembled unit? Can the chrome pipe be cut to fit?

Answered By QS Team

The total height will not be greater than 1200mm, and the chrome pipe has no thread for the fixing; this means you can cut this to your desired height.
