Grohe Rapid SL For WC With Flushing Cistern

Grohe Rapid 39002000 Details

Install your WC using the Grohe Rapid SL for WC with Flushing Cistern Using this unit; you can install wall-hung WCs to an external wall surface or stud walls. It includes a flush pipe for external odour extraction and also has access for maintenance. It gives you 1.13 m finished installation height and is a self-supporting design with powder-coated steel framework. It is useful in dry-cladding, completely pre-assembled with fixed connections. Complete with adjustment, fixing for WC and ceramic, this low noise unit is also insulated against condensation. The product can be used both for vertical or horizontal use.

Manufacturing code of this product: 39002000
Flushing cistern GD 2 6 l - 3 l
With maintenance access
1.13 m finished installation height
For on-the-wall installations or studded walls
For dry-cladding, completely pre-assembled with fixed connections
For single or series installation
Quick adjustment, lockable
Fixing material
2 WC fixing bolts
Fixing device for ceramic
WC ceramics with a small bearing area (< 205 mm) require additional accessories - 38779000 [Optional]
Distance of fixing bolts 180/230mm
Outlet bend Ø 90mm
Depth adjustable
Reducer Ø 90/110mm
Inlet and outlet connecting set
Adjustment ex-factory 6 l and 3 l
Flush pipe with connection for odour extraction 50 mm
Pneumatic discharge valve offering two modes of
Operation: dual flush or single flush
Water supply from left/right or back
Low noise (group I acc. to German Noise Specification)
Insulated against condensation
1/2 inch water supply connection including integrated angle valve and push-fit flexible hose union
No tools are required for the installation of the inspection shaft incl., including protection during the construction phase
For vertical or horizontal use
Without front wall brackets - 3855800M (pair) [Optional]
For mounting of small flush plates, please order revision shaft - 40911000 [Optional]
Size In [mm]: 500mm x 1130mm [Width x Height]
Size In [cm]: 50cm x 113cm [Width x Height]
Download the Installation Instruction PDF File From The Additional Info Section
Refer to the technical diagram for technical detail
