Triton Dene Chrome Concentric Mixer Shower Set With Thermostatic Control

Triton Dene UNDETHEXCM Details

Triton Dene Concentric Mixer Shower Set features riser rail kit with adjustable wall fixing centres and a three spray pattern showerhead. It comes with the independent flow and temperature controls facing in front. When you need to install this kit, it becomes quick and easy as it comes with all the necessary fittings. It has a thermostatic mechanism that keeps the temperature within a specified range even when the flow of water fluctuates. The sleek polished chrome unit also works to shut down automatically when required. It works with all plumbing systems and is backed by five years of guarantee against any manufacturing defects.

Manufacturing code of this product: UNDETHEXCM
It comes in a fabulous chrome finish
Head diameter: Ø84mm
Height: 230mm
Valve size in [mm]: 150mm x 127mm x 84mm [Width x Depth x Height]
Valve size in [cm]: 15cm x 12.7cm x 8.4cm [Width x Depth x Height]
Rail diameter: Ø19mm
Rail length: 530mm
Shower head holder mechanism: push-button release
Hose length: 1250mm
Separate forward-facing flow and temperature controls
Includes all necessary fittings for easy installation
Open outlet flow rate: 4.3 l/min @ 0.1 Bar
Maximum flow rate with flow limiters fitted: 8 l/min
Features automatic shutdown
Separate flow and temperature controls
Adjustable distance between rail brackets
Shower head holder mechanism push-button release
Supplied with soap dish
Incorporates with hose retainer
Rub clean nozzles
Hose material: double interlocked stainless steel
Suitable for all plumbing systems
Water entry points: rising, falling, back
Inlet connections: 15mm female compression (nuts and olives supplied)
Pipe inlet centres: 150mm
Outlet connection: 1/2 inch BSP bottom
Minimum running pressure/flow: 0.1 Bar @ 8 l/min
Maximum running pressure: 5 Bar
Maximum static pressure: 10 Bar
Approvals: WRAS
Refer to the technical diagram for complete technical dimensions
Download the Installation Instruction PDF File From The Additional Info Section

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Country of Origin
: UK
⤷ Warranty/Guarantee
: 5 Years
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Exposed
⤷ Inlet Centres
: 150
⤷ Hose Included
: Yes
⤷ Hose Length
: 1250
⤷ Spray Setting
: 3
⤷ Flow Rates (l/min)
: 4.3 l/min @ 0.1 Bar
⤷ Configuration
: Shower with Kit
⤷ Temperature Control
: Thermostatic

⤷ Compliance/Approvals/Standard
: WRAS
⤷ Soap Dish Included
: Yes
⤷ Showerhead Finish
: Chrome
⤷ Hose Type
: Double Interlocked Stainless Steel
⤷ Riser Rail & Kit Finish
: Chrome
⤷ Separate temperature and power controls
: Yes
⤷ Water Entry Points
: Rising, Falling, Back
⤷ Auto shutdown if hot or cold supplies fail
: Yes
⤷ Spray Patterns (Shower Handset)
: 3
⤷ Valve Size
: 150
⤷ Rail Length
: 530
⤷ Flow Limiters Supplied
: Yes

Additional Info & Downloads

Download the Installation Instructions Of Valve Pdf File Download the Installation Instructions Of Handset Pdf File Download the Installation Instructions Of Rail Pdf File

Triton Dene Chrome Concentric Mixer Shower Set With Thermostatic Control

£165.46

RRP: ~~£222.34~~

STOCK AVAILABLITY: 4 Working Days Approx

QS Supplies

3 Features Included In This Product Explained

Suitable For Gravity Fed System

Usually found in old properties, Gravity-Fed Systems are known for their low water pressure.

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws.
Read more...

Questions & Answers

Submit Your Questions 1 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Raif Asked :
Is this OK for low-pressure, gravity-fed?

Answered By QS Team

Yes, the Dene shower works with low-pressure, gravity-fed systems. It needs a minimum of 0.1 bar and 8 litres per minute.
