Geberit Sigma60 214 x 132mm Dual Flush Plate For Even Surface

Geberit Sigma60 115.640.GH.1 Details

Geberit Sigma60 Dual Flush Plate features a space-saving design with surface-even front actuation and a sleek two-button display. Its made from die-cast zinc or glass with chrome plating and built with sound-absorbing actuator rods for exceptionally quiet actuation. Choose from different finish options. It comes with fastening material and a protection plate for your convenience. You can get this unit from our online store at a discounted price, get it today!

Material variant: Die-cast zinc, glass and Die-cast zinc - [Optional]
Size [mm]: 214mm x 132mm [Width x Height]
Size [cm]: 21.4cm x 13.2cm [Width x Height]
Button Finish: Available in 3 finishes [Optional
Design strip: Mirrored
Frame: Gloss Chrome Plated
Front actuation
Sigma60 Cover frame [Optional]
Rough Installation set for Sigma concealed cistern 12cm [Optional]
Refer to the technical drawing for more technical specifications
Download the Installation Manual PDF File from the Additional Info Section
For more details, refer to PRODUCT VARIATIONS INFO and MFC CODE table given below
Application purposes:
For flush actuation with Geberit Sigma concealed cisterns 8cm, Series 2016
For flush actuation with Geberit Sigma concealed cisterns 12cm
For covering thicknesses of 24-50mm
Not suitable for Geberit Duofix elements for wall-hung WC, barrier-free
Scope of delivery:
Compensation frame
2x spacers
2x distance bolts
2x actuator rods
Protection plate
Fastening material

Note: Not suitable for use with extension rods

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Brushed Chrome-Plated
⤷ Shape
: Rectangular
⤷ Country of Origin
: Germany
⤷ Material
: Die-cast Zinc / Glass

⤷ Flush Type
: Dual Flush
⤷ Width
: 214
⤷ Height
: 132

Additional Info & Downloads

Download the Installation Manual Pdf File

Add-Ons

Cover Frame For Flush Plate

This Geberit cover frame for flush plate is available in different finishes. Please Note: The image shown is for illustration purpose only.

No Option Selected
OP-142124 - Cover Frame In Brushed Chrome-Plated Finish + £119.70
OP-142123 - Cover Frame In Gloss Chrome-Plated Finish + £119.70

Optional Rough Installation Set

The rough installation set from Geberit for Sigma60 surface-even flush plates is only suitable to use with Sigma concealed cistern 12cm. Please Note: The image shown is for illustration purposes only.

No Option Selected
OP-179823 - Rough Installation Set For Sigma Concealed Cistern 12cm + £9.19

Geberit Sigma60 214 x 132mm Dual Flush Plate For Surface Even

£327.36

RRP: ~~£649.92~~

IN-STOCK

Delivery in 2 Working Days Approx.

QS Supplies

1 Features Included In This Product Explained

Zinc

Zinc is a versatile, lustrous metal that is corrosion-resistant and alloys easily with other metals to enhance their properties. While relatively brittle at room temperature, zinc becomes malleable when heated, allowing it to be shaped for various applications.
