Geberit Monolith Sanitary Module For Wall-Hung WC 505 x 1140mm

Geberit Monolith 131.031.SI.5 Details

Geberit Monolith Sanitary Module for Wall-Hung WC has a stylish, smooth glass surface and features dual flush mechanism. It features front cladding made of glass while side cladding made of brushed aluminium. The self-supporting unit features adjustable flush volume with water supply connection on the left or right with accessories. The unit is compatible for use in renovations, conversions and new buildings and for replacing low-level exposed cisterns, half-high level exposed cisterns, wall-hung WCs with close-coupled exposed cistern and more.

Available in 4 finishes on Glass surfaces and two finishes on Stoneware surfaces
Available finish in Glass: White, Lava, Sand Grey and Black
Size [mm]: 505mm x 1140mm [Width x Height]
Size [cm]: 50.5cm x 114cm [Width x Height]
Glass Thickness: 8mm (0.8cm)
Height adjustable up to 7 cm
Fastening height WC ceramic appliance 35 ± 1 cm
Cistern fully insulated against condensation
Self-supporting
Adjustable flush volume
Water supply connection on the rear centre
Water supply connection on the left/right possible with accessories
Water supply connection on the bottom
Flow pressure 0.1-10 bar
Maximum operating temperature, water 25 deg.C
Flush volume, factory setting 6 and 3 l
Flush volume large, adjustment range 4.5 / 6 l
Flush volume small 3 l
Calculated flow rate 0.11 l/s
Minimum flow pressure for calculated flow rate 0.5 bar
Water supply Side connection Set and Vario Fastening Set [Optional]
Application purposes
For renovations, conversions and new buildings
For wall inlets with inlet height > 23 cm
For replacing low-level exposed cisterns
For replacing half-high level exposed cisterns
For replacing wall-hung WCs with close-coupled exposed cistern
For replacing wall-hung WCs with a pressure-flushing valve
For replacing wall-hung WCs with concealed cisterns with a maximum service opening height of < 109 cm
For Geberit AquaClean WC complete solutions
For connecting Geberit AquaClean WC enhancement solutions with accessories
For mounting on finished floors
For installation in front of drywalls or solid walls
For compensating the offset between WC connections and wall drains, using a stepped straight connector for wall-hung WCs
Scope of delivery
Water supply connection set with two angle stop valves, 1/2 inch
Flush bend extension 160 mm
Sleeve made of EPDM, diameter 44 / 55 mm
Straight connector made of PE-HD, diameter 90 mm
Adaptor socket made of PE-HD, diameter 90 / 110 mm
Two threaded rods M12
Sound insulation set
Base cover
Fastening material for drywall
Fastening material

Info / Size (mm)

Frame
Width: 505 mm
Height: 1140 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: White Glass
⤷ Country of Origin
: Germany
⤷ Flush Type
: Dual Flush

⤷ Width
: 505
⤷ Height
: 1140
⤷ Water Supply Connections
: Rear Centre, Bottom or Left/Right

Additional Info & Downloads

Download the Installation Instruction Pdf File

Add-Ons

Water Supply Connection

Geberit provides you with an ultimate solution for lateral water supply connection by introducing Monolith Set, which is available for left or right-hand installation.

No Option Selected
OP-142453 - Lateral Water Supply Connection Set For WC + £71.59

Geberit Monolith Sanitary Module 505 x 1140mm For Wall-Hung WC

£840.08

RRP: ~~£1658.23~~

STOCK AVAILABLITY: 3-4 Working Days Approx

QS Supplies

2 Features Included In This Product Explained

Dual-Flush

A toilet with a flushing mechanism with two different buttons for flushing solid and liquid waste, thereby saving water.

Drywall

Drywall, or wallboard, also called plasterboard or gypsum board, is a common building material used in interiors for constructing walls and ceilings. Drywall is gypsum plaster in the middle with layers of paper or fiberglass mats on either side. Drywalls do not need mortar or plaster. The gypsum core is rigid, and the other surface is smooth.
