Geberit Monolith Plus 480 x 1010mm Sanitary Module For Floor-Standing WC

The Geberit Monolith Plus Sanitary Module for Floor-Standing WC is a self-supporting unit that includes a cistern that is fully insulated against condensation and side cladding that is made up of brushed aluminium. Designed to be used within a wide variety of different bathroom layouts, this unit offers an adjustable flush volume and a user detection range that can be set. Complete with soft-touch buttons for both flush actuation and odour extraction, this model also features ceramic honeycomb filter that can be installed, and replaced, without tools of any kind.

• Front cladding: Glass and Stoneware
• Side cladding: aluminium and black chrome aluminium
• Size [mm]: 480mm x 106mm x 1010mm [Width x Depth x Height]
• Size [cm]: 48cm x 10.6cm x 101cm [Width x Depth x Height]
• Refer to the technical drawing for more details
• Settings can only be changed with the Geberit Home App
• The user detection range can be set
• Odour extraction with a ceramic honeycomb filter can be activated
• Odour extraction unit with run-on function
• Ceramic honeycomb filter for odour neutralisation can be replaced without tools
• Lighting mood is infinitely adjustable from orientation light to daylight
• Light colour continuously adjustable from warm white to cool white
• DALI-compatible control
• Operation with extra-low voltage, no mains voltage in the cistern
• Mains connection with flexible three-core sheathed cable
• Water supply connection on the bottom
• Water supply connection on the left/right possible with accessories
• Compensation of dimensional tolerances possible
• Cistern, fully insulated against condensation
• Side cladding made of aluminium brushed
• Self-supporting
• Protection degree: IPX4 rated
• Protection class: I
• Nominal voltage: 100-240 V AC
• Mains frequency: 50-60 Hz
• Operating voltage: 12 V DC
• Power consumption: 15 Watts
• Power consumption standby: ≤ 0.5 Watts
• Flow pressure: 0.1-10 bar
• Maximum operating temperature, water: 25 degrees Celsius
• Flush volume factory setting: 6 and 3 litres
• Flush volume large adjustment range: 4-6 litres
• Flush volume small: 3 litres
• Light colour: 2200-4000 Kelvin
• Application Purposes
• For floor inlets
• For renovations, conversions and new buildings
• For wall inlets with an inlet height of 18 cm
• For floor-standing WCs with P-bend and water inlet height 32-36cm above the floor (EN 33)
• For replacing low-level exposed cisterns
• For replacing floor-standing WCs with close-coupled exposed cistern
• For connecting Geberit AquaClean Tuma WC complete solution floor-standing WC
• For connecting Geberit AquaClean WC enhancement solutions with accessories
• For mounting on finished floors
• For installation in front of drywalls or solid walls
• Scope Of Delivery
• Water supply connection set with two angle stop valves half-inch
• Flush bend extension 160mm
• The sleeve is made of EPDM diameter 44 / 55mm
• Connection bend made of PP diameter 90mm
• Adaptor socket made of PE-HD diameter 90 / 110mm
• Female socket for mains connection
• Power supply unit
• Base cover
• Fastening material
• Drywall fastening material
