Tavistock Structure 505mm White Wall Hung WC Pan With Soft Close Seat

Tavistock Structure WH450S Details

The Tavistock Structure Wall Hung WC Pan with Soft Close Seat is a sleek, compact unit meant for wall-mounted installation and includes a slim, soft-close seat for a fully functional product overall. This unit only consists of the WC pan and seat as part of the package; the cistern, flush plate and WC frame can be purchased separately. With an easy-to-install seat with a top-close mechanism for easy cleaning, this unit makes an impressively chic addition to any incredibly fashionable bathroom set-up.

The manufacturing code of this product is: WH450S|TS451S-SF
It comes in a white finish
Wall-mounted installation
Projection: 505mm (50.5cm)
Structure slim soft close seat included
Size [mm]: 340mm x 322mm [Width x Height]
Size [cm]: 34cm x 32.2cm [Width x Height]
Inner Bowl Depth: 320mm (32cm)
Inner Bowl Width: 240mm (24cm)
Wall-hung pans must be installed with a suitable frame design, and you will need to choose your flush plate or button [See Option]
Refer to the technical drawing for more details
Download the Technical Data Sheet PDF File from the Additional Info Section
Price includes WC Pan and Seat only and does not include any Cistern, Flush Plate, WC Frame or any other item shown in the image

Info / Size (mm)

Pan Size
Width: 340 mm
Projection: 505 mm
Height: 322 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Structure
⤷ Colour
: White
⤷ Warranty/Guarantee
: 20 Years
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Projection (Depth)
: 505
⤷ Width
: 340
⤷ Configuration
: WC Pan And Seat
⤷ Compact Design
: Yes
⤷ Height
: 322
⤷ Seat Included
: Yes

⤷ Seat Type
: Soft Close
⤷ Seat Finish
: White
⤷ Fixings included
: Yes
⤷ Fixing Holes Centre
: 180
⤷ Barcode
: 5016519413991
⤷ Bowl Shape
: Square
⤷ Product Type
: Wall Hung WC
⤷ Seat Post Hole Centers
: 155
⤷ Front Of Bowl To Centre Of Seat Holes
: 430
⤷ Base width
: 230
⤷ Pan fixing centres
: 180

Additional Info & Downloads

Download the Technical Data Sheet Pdf File

Add-Ons

WC Frame

Frame comes complete with a dual flush 6/3 litre concealed cistern. Note Image is for illustration purpose only.

No Option Selected
OP-142006 - W 500 x H 820 x D 167-215mm + £203.50
OP-142007 - W 500 x H 1168 x 140-200mm + £203.50

Optional Flush Plate

The flush plate is compatible with a wall-hung WC frame and concealed cistern as an optional upgrade. The image shown is just for illustration purposes only.
