Nuie Lawton 625mm Compact Pan White With Cistern

Nuie Bathroom Lawton CLW001 Details

Nuie Lawton 625mm Compact Pan with Cistern will add personality and convenience to your bathroom while also improving its style. The unit has a compact profile with a reduced projection from the wall ideal for the smaller bathroom. It is manufactured from high quality vitreous china. It has a size of 805 millimetres in height by 360 millimetres in width by 625 millimetres in-depth, making it spacious enough for storage and strong enough to be backed by five years guarantee from the manufacturer against any manufacturing defects.

Former Known as Premier Lawton Compact Pan With Cistern - CLW001
The manufacturing code of this product is CLW001
It comes in a white finish
Compact with a reduced projection from the wall, ideal for the smaller bathroom
Semi flush-to-wall pan option is easier to install and conceals unsightly pipework
Overall size [mm]: 360mm x 625mm x 805mm [Width x Projection x Height]
Overall size [cm]: 36cm x 62.5cm x 80.5cm [Width x Projection x Height]
Refer to the technical diagram for more technical detail
Detail For Short Projection Pan:
P Trap style
Seat Hinge Type: Top Fix
Weight: 23.7 kg
Size [mm]: 360mm x 625mm x 400mm [Width x Projection x Height]
Size [cm]: 36cm x 62.5cm x 40cm [Width x Projection x Height]
Detail For Curved Cistern:
Fitting: Loose 6/3L
Push-button flush mechanism
Lever-type: Plastic chrome plated
Size [mm]: 365mm x 137mm x 393mm [Width x Depth x Height]
Size [cm]: 36.5cm x 13.7cm x 39.3cm [Width x Depth x Height]
The seat and cover shown in the image are not included

Info / Size (mm)

Toilet
Width: 360 mm
Projection: 625 mm
Height: 805 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Lawton
⤷ Toilet Design
: Open Back
⤷ Coating
: Without Coating
⤷ Colour
: White
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Vitreous China
⤷ Theme
: Modern
⤷ Installation Type
: Floor Mounted
⤷ Pan Width
: 360
⤷ Pan Height
: 400
⤷ Toilet Overall Height
: 805
⤷ Projection (Depth)
: 625
⤷ Cistern Included
: Yes
⤷ Cistern Width
: 365
⤷ Cistern Height
: 393
⤷ Full Flush Volume in litres
: 6
⤷ Half Flush Volume in litres
: 3

⤷ Flush Mechanism
: Push Button
⤷ Cistern Lever Or Button Placement
: Top
⤷ Outlet
: Horizontal
⤷ Configuration
: Pan | Cistern
⤷ Seat Included
: Sold Separately
⤷ Seat Type
: Soft-Close
⤷ Seat Finish
: White
⤷ Compliance/Approvals/Standard
: CE | UKCA
⤷ Barcode
: 5055275867440
⤷ Bowl Shape
: Round
⤷ Product Type
: Closed Coupled
⤷ Cistern Depth (projection)
: 137
⤷ Seat Post Hole Centers
: 156
⤷ Base width
: 246
⤷ Base Depth (projection)
: 390
⤷ Outlet Diameter
: 100
⤷ Base to centre of outlet
: 180

Additional Info & Downloads

Download the Data Sheet Pdf File

Nuie Lawton 625mm Compact Pan White With Cistern

£135.00

RRP: ~~£387.00~~

IN-STOCK

Delivery in 2 Working Days Approx.

QS Supplies

5 Features Included In This Product Explained

Horizontal Outlet

When the pan has piping at the back, inside the wall, it is called a horizontal outlet toilet or pan. As the cisterns are concealed or placed against the wall, most plumbing is hidden out of sight.

UKCA Great Britain Mark

Merlyn enclosures now carry the UKCA mark, which stands for UK Conformance Assessment. This mark indicates that the product meets or exceeds GB-designated standards. The UKCA mark is now the standard labelling for products sold in Great Britain (England & Wales & Scotland).

Vitreous-China Material

Vitreous china is an innovative glass-based enamel coating applied to porcelain. This glazed coating makes the base material durable, denser, and very glossy. When ceramics are coated with vitreous enamel, the resulting product is called vitreous china. This enamel is created by applying heat to powdered glass.

Compact Toilet

True to its name, a compact toilet has smaller dimensions and takes up less space by incorporating design changes such as a smaller tank, seat, and a round rather than an elongated bowl. Also, a toilet with a depth of under 500mm can qualify as a compact toilet. However, a compact toilet can be subjective as it depends on the size of your bathroom and what size of toilet your bathroom can accommodate.

Open-Back Toilet

Open-back toilets are a type of close-coupled toilet with a cistern attached to the back of the toilet, creating one single unit. In the open-back model, there is a space at the back between the toilet bowl and the wall to access pipework at the back, while the closed back does not have a gap.

Reviews & Ratings

By: Julian From : Oxford Overall Rating: Date: December 8, 2020 A Perfect Loo

This is a short projection toilet, perfect for my small ensuite bathroom. Looks great and sits well with perfect flush controls for heavy or small loads. A joy to use
