Mira Honesty EV Thermostatic Bar Mixer Shower Chrome

Mira Honesty 1.1901.001 Details

Mira Honesty EV Thermostatic Bar Mixer Shower is a WRAS approved unit that is suitable for installation within all pressure systems. Complete with thermostatic temperature control, this product is designed to fit beautifully within any modern or contemporary bathroom layout. Manufactured from nothing but high-quality materials from the inside out, any user is certain to appreciate both the form and the appearance that this unique unit offers. Complete with separate flow and temperature controls, the mixer comes with 5 years of warranty from the manufacturer against any manufacturing defects.

The manufacturing code of this product is 1.1901.001
It comes in a chrome finish
Thermostatic temperature control
Automatic shutdown: Shutdown within 2 seconds
Supplied with a light touch clamp bracket designed for easy one-handed use
Features 110mm (11cm) single-mode hand shower designed for maximum flow
Adjustable maximum temperature stop
Cool shield ensures the valve doesn’t get hot during the shower
Water entry points: Rear
Inlet connections: 15 mm (1.5cm) compression, 3/4 inch BSP to Valve
Outlet connections: 1/2 inch BSP Male to flexible hose
Reversed inlets supported: No, Hot - Left, Cold - Right
Cold water range: Up to 25°C
Hot water range: 60°C-65°C (recommended)
Compatible with all plumbing systems
Consistent flow, even at low pressure
Minimum maintained pressure: 0.1 bar (1-meter head)
Maximum maintained pressure: 5.0 bar (50-meter head)
Maximum static pressure: 10.0 bar (100-meter head)
Flow rate (Rain): 9.3 l/min at 0.5 bar
Valve only: 12.9 l/min at 0.5 bar
Temperature stability: ± two °C
Factory set to safe max temp: Factory set to 46°C
Refer to the technical drawing for more size details
Download the Installation Instruction and User Guide PDF File from the Additional Info Section

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Country of Origin
: UK
⤷ Warranty/Guarantee
: 5 Years
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Bar
⤷ Inlet Centres
: 150
⤷ Minimum Operating Pressure (Bar)
: 0.1
⤷ Hose Included
: Yes
⤷ Flow Rates (l/min)
: 9.3 at 0.5 bar
⤷ Technologies
: Cool shield™
⤷ Temperature Control
: Thermostatic

⤷ Plumbing System Compatibility
: Suitable For All Plumbing Systems
⤷ Riser Rail & Kit Finish
: Chrome
⤷ Separate temperature and power controls
: Yes
⤷ Adjustable maximum temperature stop
: Yes
⤷ Water Entry Points
: Rear
⤷ Auto shutdown if hot or cold supplies fail
: Yes
⤷ Handset Included
: Yes
⤷ Spray Patterns (Shower Handset)
: 1
⤷ Valve Size
: 288
⤷ Rail Length
: 562

Additional Info & Downloads

Download the Installation Instructions And User Guide Pdf File

Mira Honesty EV Thermostatic Bar Mixer Shower Chrome

£248.06

RRP: ~~£299.29~~

IN-STOCK

Delivery in 2 Working Days Approx.

QS Supplies

4 Features Included In This Product Explained

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

Mira Cool Shield™

With the purpose of giving you enhanced safety during showering, the cool shield technology features in all of Mira's mixer showers. This is an innovative technology that prevents heating up of the valve during a shower, so it remains cool to the touch, making it ideal for use in homes with children or elders.

BSP Male Connector

British Standard Pipe (BSP) are a group of internationally accepted standards for threads for interconnecting hoses and fittings by mating an external (male) thread with an internal (female) thread. A BSP male connector also called Plug is a kind of threaded fitting used in plumbing and piping systems. It comes attached to a wire or hardware, has an exposed electrical terminal which fits into a receptacle (called female connector to complete the electrical connection.
