Duravit B.1 Chrome Wall Mounted Thermostatic Shower System

Duravit B.1 B14280008010 Details

Duravit B.1 Wall Mounted Thermostatic Shower System includes Rail, Shower Head, Shower Arm, Valve, Handset and Hose and is thermostatic to keep the temperature constant and safe. The entire set has been given a chrome finish that gives it a long life and protects it from wear and tear. It has a safety lock at 38 Deg C and offers a flow rate of 15.3 l/min at 3 bar. Its optimal operating pressure is between 3 - 5 bar, and the unit is backed by 5 years warranty from the manufacturer.

The manufacturing code of this product is B14280008010
Pack Includes: Valve, Rail, Shower Arm, Shower Head, Handset and Hose
It comes in a chrome finish
Thermostatic cartridge
Rail Height: 1220mm (122cm)
Valve Width: 260mm (26cm)
Diameter of 1 Spray pattern Shower Head: 250mm (25cm)
Diameter of 3 Spray pattern Handset: 110mm (11cm)
Adjustable height hand shower holder and angle shower head
Hose Length: 1600mm (160cm)
A non-return valve in the hose connection
Inlet connection: G1/2-Inch
Hose connection: DN15
Centre distance: 150mm ± 20mm(15cm ± 2cm)
Recommended operating pressure of 3 - 5 bar
Flow rate 15.3 l/min at 3 bar
Download the Installation Instructions PDF from the Additional Info section
Refer to the technical diagram for more size details

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Country of Origin
: Germany
⤷ Warranty/Guarantee
: 5 Years
⤷ Theme
: Modern
⤷ Inlet Centres
: 150 ± 20mm
⤷ Inlet Connections
: G1/2-Inch
⤷ Minimum Operating Pressure (Bar)
: 3
⤷ Hose Included
: Yes

⤷ Hose Length
: 1600
⤷ Configuration
: Shower Set
⤷ Height
: 1220
⤷ Handset Included
: Yes
⤷ Spray Patterns (Shower Handset)
: 3
⤷ Spray Patterns (Shower Head)
: 1
⤷ Shower Head Included
: Yes
⤷ Shower Head Size
: Ø250

Additional Info & Downloads

Download the Mounting Instruction Pdf File

Duravit B.1 Chrome Wall Mounted Thermostatic Shower System

£620.92

RRP: ~~£1030.80~~

STOCK AVAILABLITY: 6 Working Days Approx

QS Supplies

2 Features Included In This Product Explained

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.
