Vado DX Elements 1 Outlet 2 Handle Concealed Chrome Thermostatic Valve

Vado Elements ELE-148D/SQ-CP Details

Vado DX Elements 1-Outlet 2-Handle Concealed Thermostatic Valve With Soft Square Backplate can be purchased in 3 variations of 1 Outlet / 2 Outlet / 3 Outlet. It brings the traditional style to modern interiors and is a natural choice for renovating or recreating the classic period look in your shower enclosure. It is dual-controlled so that water flow and temperature can be independently operated.

Cross-headed style handles give the user full control over their shower water for a balanced shower. The thermostatic cartridge ensures a safe and comfortable showering experience, stopping all water flow in the event of loss of cold or hot water to prevent scalding. Includes bleed valve for system flush on installation.

Available in 3 variants: 1 Outlet, 2 Outlet, 3 Outlet
It comes with two handles
Wall-mounted installation
With a square backplate
Size [mm]: 130mm x 200mm [Width x Height]
Size [cm]: 13cm x 20cm [Width x Height]
Minimum operating pressure 0.2 bar Low Pressure (shower), 1.0 bar High Pressure (bath)
Can fit into a 50mm stud wall when using an optional studfast bracket [See Option]
Refer to the technical diagram for more technical details
Download the Installation Instruction PDF File from the Additional Info Section
Fifteen years of guarantee from the manufacturer
Specification For 1 Outlet:
Concealed 1 outlet, 2 handles thermostatic valve
Thermostatic cartridge V-001C-PLA
Flow cartridge C-301-RTC
2x 3/4 inch female inlets
1x 3/4 inch female outlet
Includes 3/4 inch - 1/2 inch adaptors
Min-max wall mount 70-95mm (7-9.5cm)
Optimum installation depth 82mm (8.2cm)
Specification For 2 Outlets:
Concealed 2 outlets, 2 handles thermostatic valve
Thermostatic cartridge V-001C-PLA
Diverter cartridge FL-804-33X/3X
2x 3/4 inch female inlets
2x 3/4 inch female outlet
Includes 3/4 inch - 1/2 inch adaptors
Includes bleed valve for system flush on installation
Min-max wall mount 70-95mm (7-9.5cm)
Optimum installation depth: 82mm (8.2cm)
Specification For 3 Outlets:
Concealed 3 outlets, 2 handles thermostatic valve
Thermostatic cartridge V-001C-PLA
Diverter cartridge FL-804-33X/3X
2x 3/4 inch female inlets
3x 3/4 inch female outlet
Includes 3/4 inch - 1/2 inch adaptors
Includes bleed valve for system flush on installation
Min-max wall mount 70-95mm (7-9.5cm)
Optimum installation depth: 82mm (8.2cm)

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Shape
: Rectangular
⤷ Warranty/Guarantee
: 15 Years
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Overall Height
: 200
⤷ Inlet Connections
: 3/4-Inch
⤷ Minimum Operating Pressure (Bar)
: 0.2 bar - Low Pressure [Shower], 1.0 bar - High pressure [Bath]

⤷ Handle Style
: Crosshead Handle
⤷ Temperature Control
: Thermostatic
⤷ Backplate Width
: 130
⤷ Backplate Height
: 200
⤷ Number of Handles
: 2
⤷ Number of Outlet
: 1, 2, 3
⤷ Maximum Operating Pressure (Bar)
: 1.0

Additional Info & Downloads

Download the Installation Guide 1 Outlet Pdf File Download the Installation Guide 2 Outlet Pdf File Download the Installation Guide 3 Outlet Pdf File

Add-Ons

Studfast Brackets

The Studfast is an easy, secure and robust method of mounting thermostatic shower valves into stud walls to create a firm and trouble-free installation. Please Note: The image shown is for illustration purposes only.

No Option Selected
OP-44782 - Studfast Concealed Wall Bracket + £34.49

Videos

Video of Attaching A Shower Valve And Fitting To The Wall Stud

Vado DX Elements 2 Handle Concealed Thermostatic Valve With Soft Square Backplate

£350.75

RRP: ~~£575.00~~

STOCK AVAILABLITY: 3 Working Days Approx

QS Supplies

5 Features Included In This Product Explained

1-Outlet

One outlet in a shower system means that hot and cold water flows from a single opening.

Diverter

A diverter, specifically in bath-shower combos, redirects the water flow from the bathtub spout to the showerhead. You can activate it using the nozzle in the bath shower mixer tap.
Read more...

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

Reviews & Ratings

By: Sara From : Coventry Overall Rating: Date: November 23, 2023 A Good upgrade

Recently, I Upgraded our bathroom with the Vado DX EValve, and it's been a fantastic choice. The controls are easy to operate, and it's smooth and precise. The safety features, like the thermostatic cartridge, provide a secure showering experience. Installation was easy. I highly recommend it.
