RAK Top/Front Flush Concealed Cistern And Frame For Wall Hung Pans - Frame Height 82cm

£178.00

RRP: £435.00

STOCK AVAILABLITY:

4 Working Days Approx.

Not Yet Rated No Rating

Shipping: £7.95

Key Features
  • Flush Capacity: 6/3L adjustable to 4.5/3L
  • Suitable for use with wall-hung pans
  • Easy to clean and install
  • Frame Material: Metal
  • Two-year guarantee from the manufacturer
SKU Code: QS-V103120

MFC Code: FS04RAK82TF.01

RAK Top/Front FS04RAK82TF.01 Details

The RAK Top/Front Flush Concealed Cistern And Frame For Wall Hung Pans - Frame Height 82cm is a top-quality, easy to clean design capable of withstanding a hefty load if required. Featuring new and elegant push plates that integrate perfectly with any style of dual flush system, this unit instantly reduces water consumption and is suitable for use with wall-hung pans. Created from solid metal and ideal for low-height situations, this product provides top or front actuation and two possible flush capacities; 6 and 3-litres or 4.5 and 3-litres. Save space in your bathroom and offer true functionality all at once with this high-quality unit.

  • Orange/White colour
  • 12cm Low-height situations
  • Special element height 82cm, with top or front flushing actuation
  • Frame width: 500mm - (50cm)
  • Frame Depth: 120mm - (12cm)
  • Frame height: 820mm - (82cm)
  • Mounting: Wall
  • Listen Colour: White
  • Refer technical diagram for more details
  • RAK-Ecofi flushing systems by RAK Ceramics are the ideal solution for all types of hydro-sanitary systems
  • Invisible built-in flushing systems combine functionality and aesthetics, saving space in every bathroom
  • The new and elegant push plates integrate perfectly with any style and design of dual flush systems to reduce water consumption
  • Top-quality
  • Withstanding heavy load
  • Beautiful design
  • Water-Saving
  • Flush Plate sold separately (See Option Below)

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Colour
  • : Orange
  • ⤷ Country of Origin
  • : Dubai
  • ⤷ Warranty/Guarantee
  • : 2 Years
  • ⤷ Material
  • : Metal
  • ⤷ Cistern Included
  • : Yes
  • ⤷ Flush Type
  • : Dual Flush
  • ⤷ Full Flush Volume in litres
  • : 6
  • ⤷ Half Flush Volume in litres
  • : 5
  • ⤷ Width
  • : 500
  • ⤷ Depth
  • : 120
  • ⤷ Height
  • : 820
  • ⤷ Flush Plate Included
  • : Sold Separately

Add-Ons

Optional Flush Plate
Optional Flush Plate

Optional Flush Plates Available in different finishes. Note: Image is for illustration purpose only.

£178.00
RRP: £435.00
STOCK AVAILABLITY: 4 Working Days Approx
QS Supplies

1 Features Included In This Product Explained

Dual-Flush

Dual-Flush

A toilet with a flushing mechanism with two different buttons for flushing solid and liquid waste, thereby saving water.

Reviews & Ratings

Rate this Item.:

Questions & Answers

Submit Your Questions 4 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Leon Asked :

I have a box unit which is 18mm thick and 500mm wide on the outside to outside of the unit, and I was wondering if this frame fits directly into a 500mm box or if the frame is exactly 500mm wide or a bit narrower.

Answered By QS Team Answered by the QS Technical Team

The frame is exactly 500mm wide, I'm afraid.

Was this answer helpful?
Penny Asked :

Is this product compatible with water supply from left/right or back?

Answered By QS Team Answered by the QS Technical Team

The water inlet is on the left side of the cistern.

Was this answer helpful?
Tony Asked :

Does this frame work with the RAK cloud rimless wall-hung WC pan?

Answered By QS Team Answered by the QS Technical Team

Yes, the RAK Top/Front Flush Concealed Cistern And Frame are compatible with the RAK Cloud Rimless Wall-Hung WC pan.

Was this answer helpful?
Renato Asked :

Hi, I just bought the RAK Top/Front from you and realised it doesn't allow the drainage to be mounted laterally, only vertically. This is due to the shape of the plastic connector, and I was wondering if I could buy a spare connector that is compatible and allows lateral rather than vertical drainage connection.

Answered By QS Team Answered by the QS Technical Team

The pipes can be removed by releasing the black plastic clamp holding it to the frame, purchasing a standard straight waste pipe, and then reattaching it to the frame using cable ties. Your plumber should be able to source a pipe from any plumber's merchants.

Was this answer helpful?
Accepted Answer 2 Thumbs Down 0
