Grohe Rapid SL 3 In 1 Set For WC With GD2 Flushing Cistern

Grohe Rapid 39501000 Details

The Grohe Rapid SL 3 In 1 Set for WC With GD2 Flushing Cistern is crafted from sleek and sturdy materials from top to bottom and fits in perfectly to any compatible modern or traditional bathroom layout. A truly impressive pack that includes a rapid SL element for WC, a Skate Cosmopolitan S Flush Plate, Rapid SL Front Wall Brackets, and a revision shaft; this product set includes nearly everything needed to set-up a compatible WC unit for use. Designed for on-the-wall installations on studded walls, this product is depth adjustable and insulated against condensation of any kind as well.

Manufacturing code of this product: 39501000
It comes in a chrome finish
Download the Installation Instruction PDF File From The Additional Info Section
Refer to the technical diagram for the technical dimension
Pack Includes:
Rapid SL Element For WC - 38528001
Skate Cosmopolitan S Flush Plate - 37535000
Rapid SL Front Wall Brackets - 3855800M
Revision Shaft - 40911000
Features Of Rapid SL Element For WC - 38528001
Flushing cistern GD 2, 6 - 9 l, containing
For on-the-wall installations or studded walls
2 WC fixing bolts
Fixing device for ceramic
WC ceramics with a small bearing area (< 205 mm) require
Distance of fixing bolts 180/230mm
Outlet bend Ø 90mm
Depth adjustable
Reducer Ø 90/110mm
Size In [mm]: 500mm x 1130mm [Width x Height]
Size In [cm]: 50cm x 113cm [Width x Height]
Inlet and outlet connecting set
Water supply from left/right or back
Insulated against condensation
1/2inch water supply connection including integrated angle valve and push-fit flexible hose union
Features Of Skate Cosmopolitan S Flush Plate - 37535000
Vertical installation
For dual flush or start and stop actuation
For pneumatic drop valve AV1
Compatible with Rapid SL/GD2 1.13 m
Flush plate with magnetic holder and fixing brackets included
GROHE EcoJoy®- [See Features Explained Section]
Size In [mm]: 130mm x 172mm [Width x Height]
Size In [cm]: 13cm x 17.2cm [Width x Height]
Features Of Rapid SL Front Wall Brackets - 3855800M
For against-the-wall installations
The adjustment from 130mm - 230mm - (13cm-23cm)
It comes with two rubber pipes
Compatible with fixing the elements at the brick wall or in front of the studded wall
Features Of Revision Shaft - 40911000
In combination with Rapid SL/GD 2 1.13 m cisterns

Info / Size (mm)

Frame
Width: 500 mm
Height: 1130 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Blue
⤷ Country of Origin
: Germany
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Powder-Coated Steel
⤷ Cistern Included
: Yes
⤷ Flush Type
: Dual Flush
⤷ Full Flush Volume in litres
: 9

⤷ Half Flush Volume in litres
: 6
⤷ Width
: 500
⤷ Depth
: 230
⤷ Height
: 1130
⤷ Fixings included
: Yes
⤷ Flush Plate Included
: Sold Separately
⤷ Water Supply Connections
: Left, Right Or Back

Additional Info & Downloads

Download the Installation Instruction Rapid SL Element For WC Pdf File Download the Installation Instruction Skate Cosmopolitan S Flush Plate Pdf File Download the Installation Instruction Revision Shaft Pdf File

Grohe Rapid SL 3 In 1 Set For WC With GD2 Flushing Cistern

£194.02

RRP: ~~£379.01~~

IN-STOCK

Delivery in 4 Working Days Approx.

QS Supplies

1 Features Included In This Product Explained

Grohe EcoJoy

According to Grohe, the EcoJoy technology enables reduced water usage by your tap by up to 50%. It is done without compromising on the water spray, which allows a full jet of water from the tap and provides excellent value and comfort in a single unit.

Questions & Answers

Submit Your Questions 1 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Matthew Asked :
Is the height adjustable?

Answered By QS Team

The feet on the frame of the Grohe Rapid SL 3 In 1 Set For WC (39501000) can be adjusted by up to 200mm. The minimum overall height is 1085mm, and the maximum is 1285 mm.
