Nuie Arvan Round Chrome Thermostatic Temperature Control Valve

Nuie Arvan ARVTC11 Details

Gift yourself refreshingly warm showering moments by bringing home this stylish Nuie Arvan Round Thermostatic Temperature Control Valve. This unit includes a valve with a cartridge, designed for use with a valve and cartridge. For enabling precision temperature control, the valve comes with advanced thermostatic technology. This unit can be used with a concealed stop tap that can be purchased separately.

Constructed from high-quality brass and ABS, it has a protective chrome polish. To fully protect you against any manufacturing faults, this unit is supported by a solid 5-year guarantee from Nuie against manufacturing defects. Fix it within a shower enclosure area to get the optimum showering experience.

The manufacturing code of the product is ARVTC11
Size [mm]: 125mm x 135mm x 125mm [Width x Depth x Height]
Size [cm]: 12.5cm x 13.5cm x 12.5cm [Width x Depth x Height]
Included 1 round handle valve
Designed for use with a concealed stop tap - Sold separately [Optional]
It comes in a chrome finish
Number of outlets: 1
Inlet and outlet connection: G.1/2
Installation type: recessed and wall
Pipe size: 15mm (1.5cm) (1/2inch BSP)
Suitable for low-pressure water system
Requires 0.1 bar operating water pressure
Download Customer Datasheet And Installation Instruction PDF File from the Additional Info Section
The technical drawing is available for more technical details

Info / Size (mm)

Valve
Width: 125 mm
Depth: 135 mm
Height: 125 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Shape
: Round
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Brass | ABS
⤷ Theme
: Modern
⤷ Installation Type
: Recessed | Wall
⤷ Overall Height
: 215
⤷ Min-Max Wall Mount
: 75-95
⤷ Inlet Connections
: G.1/2
⤷ Minimum Operating Pressure (Bar)
: 0.1 bar
⤷ Flow Rates (l/min)
: 0.1 bar-5.8 | 0.5 bar-15.1 | 1 bar-21.6 | 2 bar-30.7 | 3 bar-37.6
⤷ Handle Style
: Round

⤷ Depth
: 135
⤷ Temperature Control
: Thermostatic
⤷ Backplate Width
: 125
⤷ Backplate Height
: 125
⤷ Anti-Scald
: Yes
⤷ Number of Handles
: 1
⤷ Number of Outlet
: 1
⤷ Outlet Connection
: G.1/2
⤷ Plumbing Option
: Concealed
⤷ Overall Width
: 125
⤷ Cartridge Included
: Yes

Additional Info & Downloads

Download the Customer Data Sheet Pdf File Download the Installation Instructions Pdf File

Add-Ons

Concealed Stop Tap

Concealed stop tap with quarter-turn ceramic disc cartridge. It is made from rust-resistant brass material for long and smooth operation. Please Note: The image shown is for illustration purposes only.

No Option Selected
OP-196261 - Concealed Stop Tap RECOMMENDED
+ £47.98

Nuie Arvan Round Chrome Thermostatic Temperature Control Valve

£83.89

RRP: ~~£255.00~~

IN-STOCK

Delivery in 4 Working Days Approx.

QS Supplies

2 Features Included In This Product Explained

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
Read more...

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...
