Nuie Windon Deck Mounted Basin Mixer Tap With Push Button Waste

Nuie Windon WIN315 Details

Nuie Windon Deck Mounted Basin Mixer Tap With Push Button Waste will complement your basins in style. Fabricated from premium grade brass material, this solid brassware assures for long-term use. This deck-mounted mixer comes in chrome and matt black and goes exceptionally well with any basin, be it classic or contemporary, wall hung, vanity or pedestal. The ceramic disc cartridge offers operational ease for this unit to work with low-pressure water systems.

Choice of different finishes: Chrome, Matt Black, Brushed Brass and Brushed Pewter - [Optional]
Available in different heights: 140mm and 160mm - [Optional]
A minimum of 0.2 bar of water pressure required
Single lever cartridge type
Ideal for deck-mounted installation
Excellent flow rates, even at low-pressure
Stunning contemporary angular design
Pipe size: 1/2inch
Cartridge material: Plastic
Supplied with fixing and mounting hardware
Refer technical drawing for more details
Download the Customer Data Sheet and Installation Instruction PDF File from the Additional Info Section
Height 140mm Basin Mixer Tap:
It comes with co-ordinating push-button waste
Centre of the inlet to centre of outlet 90.5mm (9.05cm)
Size [mm]: 50mm x 135mm [Width x Depth]
Size [cm]: 5cm x 13.5cm [Width x Depth]
Flow Rate (l/min): 0.1 Bar - 2.6, 0.5 Bar - 7, 1 Bar - 10.2, 2 Bar - 14.8, 3 Bar - 18.3
Compact design perfect for use in ensuites, cloakrooms & smaller bathrooms
Height of spout: 95mm (9.5cm)
160mm Height Basin Mixer Tap:
It comes with push-button waste
WRAS approved product
Centre of the inlet to centre of outlet 109.9mm (10.99cm)
Size [mm]: 50mm x 154.5mm [Width x Depth]
Size [cm]: 5cm x 15.45cm [Width x Depth]
Height of spout: 113mm (11.3cm)
Flow Rate (l/min): 0.1 Bar - 2.8, 0.5 Bar - 7.9, 1 Bar - 11.4, 2 Bar - 16.4, 3 Bar - 20.1

Info / Size (mm)

Tap
Pipe Centre: 90.5 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Lifting | Tilting
⤷ Tap Body Shape
: Square
⤷ Handle Position
: Upward
⤷ Range
: Windon
⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: Chrome - 5 Years | Other Finishes - 3 Years
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 1
⤷ Spout type
: Fixed
⤷ Valve Included
: Yes

⤷ Valve/Cartridge Type
: Ceramic Disc Cartridge
⤷ Base To Spout
: 95
⤷ Spout Reach
: 90.5
⤷ Overall Height
: 140
⤷ Inlet Connections
: 1/2 Inch
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Waste Type
: Push Button
⤷ Flow Rates (l/min)
: 0.1 bar- 2.6 | 0.5 bar- 7 | 1 bar- 10.2 | 2 bar- 14.8 | 3 bar- 18.3
⤷ Handle Style
: Lever
⤷ Waste Included
: Sold Seperately
⤷ Barcode
: 5056211898191
⤷ Product Type
: Basin Mixer Tap

Additional Info & Downloads

Download the Customer Data Sheet For Mini Tap Pdf File Download the Customer Data Sheet For Mono Tap Pdf File Download the Installation Instruction Pdf File

Nuie Windon Deck Mounted Basin Mixer Tap With Push Button Waste

£64.19

RRP: ~~£186.00~~

IN-STOCK

Delivery in 4 Working Days Approx.

QS Supplies

4 Features Included In This Product Explained

Push Button Basin Waste

It is the perfect choice for many sink designs because of its ease of use and efficiency. The sink drain gets blocked by simply pushing the central button, allowing the water to fill in the sink. Once you are done, the water can be drained by releasing the same.

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
Read more...

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

Optional: WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws.
Read more...
