Vado Notion Concealed Thermostatic Chrome Shower Valve With Handset And Hose

Vado Notion TAB-148/2WO-NOT-CP Details

Vado Notion Concealed Thermostatic Shower Valve with Integrated Outlet Handset and Hose is elegantly designed and brilliantly efficient for everyday use. It comes with the impressive notion range of the brand with a concealed model fitted and has an All-flow function. Its contemporary design and chrome finish feature adds a modern and stylish look. The wall-mounted installation feature of the valve makes it ideal for installing anywhere in the washroom.

Available in 2 variants: 2 Outlet, 3 Outlet
Wall-mounted installation
All-flow function - 1.0 bar MOP to operate
Diverter cartridge FL-802-33/2MX
Includes 3/4 inch - 1/2 inch adaptors
Minimum to maximum wall mount 75-100mm (7.5-10cm)
Can fit into a 50mm (5cm) stud wall when using an optional studfast bracket [See Option]
For complete size, details refer to the technical drawing
Download the Installation Instruction PDF File from the Additional Info Section
Specification of 2 outlets, 2 handle
Backplate Size [mm]: 285mm x 47mm x 80mm [Width x Depth x Height]
Backplate Size [cm]: 28.5cm x 4.7cm x 8cm [Width x Depth x Height]
2 x 3/4 inch female inlets
1 x 3/4 inch female outlet, 1 x 1/2 inch male outlet
Minimum water pressure required 0.2 bar for [Low Pressure] for shower and 1.0 bar for bath [Medium Pressure]
Flow rate at 3.0 bar flow pressure: Outlet 1 24.2 outlets 2 handsets 14.6 both 29.6 l litre per minute
Specification of 3 outlets, 3 handle
Size of backplate: Width 370mm (37cm) x Depth 47mm (4.7cm) x Height 80mm (8cm)
2 x 3/4 inch female inlets
1 x 3/4 inch female outlet, 1 x 1/2 inch male outlet
Flow cartridge TAB-002A-3/4
Minimum water pressure required 0.2 bar for [Low Pressure] for shower and 1.0 bar for bath [Medium Pressure]
Flow rate at 3.0 bar flow pressure: Outlet 1 24.2 outlets 2 handsets 14.6 both 29.6 l litre per minute

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Notion
⤷ Colour
: Chrome
⤷ Shape
: Rectangular
⤷ Warranty/Guarantee
: 15 Years
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Valve Included
: Yes
⤷ Min-Max Wall Mount
: 75-100
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Hose Included
: Yes
⤷ Hand-Shower Included
: Yes

⤷ Temperature Control
: Thermostatic
⤷ Backplate Width
: 285
⤷ Backplate Height
: 80
⤷ Number of Handles
: 2
⤷ Number of Outlet
: 2
⤷ Diverter Included
: Yes
⤷ Orientation
: Landscape
⤷ Product Type
: Thermostatic Shower Valve
⤷ Plumbing System Compatibility
: Gravity System, Pumped System, Combination Boiler, Pressurised System
⤷ Plumbing Option
: Concealed
⤷ Maximum Operating Pressure (Bar)
: 1

Additional Info & Downloads

Download the Installation Instruction Pdf File

Add-Ons

Studfast Brackets

The Studfast is an easy, secure and robust method of mounting thermostatic shower valves into stud walls to create a firm and trouble-free installation. Please Note: The image shown is for illustration purposes only.

No Option Selected
OP-44782 - Studfast Concealed Wall Bracket + £34.49

Videos

Video of Attaching A Shower Valve And Fitting To The Wall Stud

Vado Notion Concealed Thermostatic Shower Valve with Integrated Outlet Handset and Hose

£579.50

RRP: ~~£950.00~~

STOCK AVAILABLITY: 3 Working Days Approx

QS Supplies

2 Features Included In This Product Explained

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

Diverter

A diverter, specifically in bath-shower combos, redirects the water flow from the bathtub spout to the showerhead. You can activate it using the nozzle in the bath shower mixer tap.
Read more...
