Tivolis Faro 1800mm High Double Panel Vertical Aluminium Radiator

Tivolis Faro 701-600475 Details

The Tivolis Faro 1800mm High Double Panel Vertical Aluminium Radiator is a truly unique and one-of-a-kind unit that features a flat double panel design that is remarkably stylish, unlike any other model on the market. It is fueled via hot water and is ideal for placement within an open or closed water system; It is available for purchase in either Anthracite or White finish options. The double Panel Radiator is designed for Vertical installation and can be used with compatible Radiator Valves, available separately.

Key Features

✔Available in Anthracite and White finish - [Optional]
✔Constructed using aluminium
✔Five-year guarantee from the manufacturer against manufacturing defects

Available in 409mm and 615mm Width [Optional]
Height: 1800mm (180cm)
Double Panel Radiator
Suitable for vertical installation
Wall to pipe centres: 70mm (7cm)
Distance from wall: 115mm (11.5cm)
Installation Type: Wall mounted
Suitable for central heating systems only
For BTU, Watts and Pipe centres, Please refer to PRODUCT VARIATIONS INFO and MFC CODE tab below
All Fittings are supplied with the product with a simple instruction manual
All Radiators from Tivolis are securely packed and protected with a Bubble Wrap
All Radiators from Tivolis have been manufactured and tested in accordance with EN442
Pipe centres are illustrative and the same with width; please add/subtract up to 90mm considering valve type for measurement
The radiator valve shown in the image is not included - Sold Separately [Optional]

Radiator Calculator

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Faro
⤷ Colour
: White
⤷ Shape
: Straight
⤷ Country of Origin
: Turkey
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Aluminium
⤷ Installation Type
: Wall Mounted
⤷ Width
: 409
⤷ Height
: 1800
⤷ Orientation
: Vertical

⤷ Compliance/Approvals/Standard
: EN442
⤷ Barcode
: 5057199957115
⤷ BTU Output
: 50°C - 3842 | 60°C - 4668
⤷ Watts
: 50°C - 1126 | 60°C - 1427
⤷ Tapping / Pipe Centres
: 409
⤷ Valves Included
: Sold Separately
⤷ Fuel Type
: Central Heating
⤷ Wall to Centre of Inlet
: 70
⤷ Panel Configuration
: Double

Add-Ons

Radiator Valves

Listed below are the compatible valves that works well with Tivolis towel rail and radiator. It is available in Angled, Straight and Corner version in Sphere, Square and TMV Modal. Please Note: Images shown are for illustration purpose only.

No Option Selected
OP-212085 - Sphere Angled Radiator Valve + £27.26
OP-212087 - Square Angled Radiator Valve + £44.41
OP-212089 - TRV MODAL - Angled Radiator Valve + £50.64
OP-212088 - Square Straight Radiator Valve + £52.82
OP-212090 - TRV MODAL - Straight Radiator Valve + £60.30

Tivolis Faro 1800mm High Double Panel Vertical Aluminium Radiator

£421.79

RRP: ~~£690.00~~

STOCK AVAILABLITY: 4 Working Days Approx

QS Supplies

Other Sizes / Finishes

Other Sizes / Finishes / Variations Available.

QS Code	Finish	Size / Difference	MFC Code
QS-V98303	-	Single Panel	701-600482

Back to QS-V98304 / MFC Code: 701-600475

Product Variations Info & MFC Code

Height	Width	Pipe Centres	BTU @Delta T50C	Watts @Delta T50C	BTU @Delta T60C	Watts @Delta T60C	White MFC	Anthracite MFC
1800mm	409mm	409mm	3842	1126	4668	1427	701-600475	701-600012
1800mm	615mm	615mm	5673	1663	7188	2107	701-600476	701-600014

2 Features Included In This Product Explained

Optional: Radiator Valve

Radiator valves help control how much hot water enters and leave it, and the flow of water controls how much heat the radiator generates. These are usually found at the radiator's bottom left, and right corners, where the water pipes enter and exit, or can also be present at the bottom near the centre.
Read more...

Double Panel Radiators

Also known as type 22 radiators, these double panel radiators are constructed using two steel panels and two convectors or sets of fins which emit greater heat output. Its heat output is more than a single panel and will heat up the room much faster. This kind is ideal for larger than average spaces.
