Keuco IXMO Chrome Thermostatic Shower Mixer Set 10 With Square Rosettes

Keuco IXMO 59605010002 Details

Keuco IXMO Square Thermostatic Shower Set 10 With Head And Slide Rail Kit is an assortment of Thermostatic Mixer Valve, Shower Head, & Hand Shower Sliding Rail. Control your showering pleasure with a product that is suitable for use with all kinds of quadrants and enclosures. This kit comes with a striking chrome finish, which can easily fit into any bathroom decor while offering it a clean and modern look. The high-quality temperature control unit is safe for the entire family, with its safety cut-off at 38 degrees C.

Chrome-plated shower set
Thermostatic Mixer :
Set complete with handle, sleeve and rosette (Square)
For recessed installation
With a square rosette, freely positionable
Installation depth 80 - 110 mm (8 - 11cm)
Built-in device for interchanged waterways
High-quality temperature control unit
Rosette 90mm x 90mm (9 x 9cm)
10mm (1cm) thick
Total depth 80mm (8cm)
Suitable for rough part no. 59553000070
Installation Unit for Thermostatic Mixer 59553000070 :
Sound-insulated rough part made of low-dezincifying brass
For recessed installation
Base plate with adjusting screws for optimal positioning
Connection G 1/2 inch with colour marking
2-Way Stop and Diverter Valve with Wall Outlet :
Set complete with handle, casing, rosette (round), and stop and diverter valve
Intrinsically safe against backflow
Suitable for rough part no. 59556 000170
Pure lever with round rosette
Freely positionable, with backflow preventer
Installation depth 80 - 110 mm (8 - 11cm)
With adjustment facilities whilst assembling for handle and rosette
With hose connection G1/2 inch
Rosette diameter 90mm (9cm)
10mm (1cm) thick
Total depth 80mm (8cm)
Installation Unit for 2-way Diverter Valve :
Rough part for recessed installation
With wall outlet for shower hose
Sound-insulated rough part made of low-dezincifying brass
Freely positionable
Installation depth 80 mm - 110mm (8 - 11cm)
Base plate with adjusting screws for optimal positioning
Connection G 1/2 inch with colour marking
Shower Head :
Square shape
Restricted flow rate 15 l/min
Size [mm]: 200mm x 200mm x 51mm [Width x Depth x Height]
Arm for shower head:
G 1/2 inch, with a round wall element
Diameter: 60mm (6cm)
Projection: 300mm (30cm)
Total projection: 312mm (31.2cm)
Shower Hose:
Shower pipe with simulated metal
Kink protection is very flexible with double-sides DN 15 conical nuts
Twist-protection at the shower head end
The conical nuts (DN 15) are a design feature, as well as high-shine chrome
Length: 1600mm (160cm)
Round Pencil Hand Shower:
Hand shower with normal jet
Normal jet flow rate 12 l/min. for combination boilers
Mounting Rail:
For an easy and adjustable installation of the IXMO function units
Shower-Set :
Rail 900mm (90cm) and hand-shower bracket
Height adjustable with handle
With adjustable tilt angle, mountable on the right or left side
Spacer disc (5 mm)
Hand shower with normal jet
Shower hose, 1600mm (160cm)

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Hose Included
: Yes
⤷ Configuration
: Complete Shower Set

⤷ Riser Rail & Kit Finish
: Chrome
⤷ Handset Included
: Yes
⤷ Shower Head Included
: Yes
⤷ Adjustable Height
: Yes

Additional Info & Downloads

Download the Installation Instruction Pdf File Download the Spare parts Pdf File

Keuco IXMO Square Thermostatic Shower Set 10 With With Head And Slide Rail Kit

£1745.92

RRP: ~~£2459.04~~

STOCK AVAILABLITY: 3-4 Working Days Approx

QS Supplies

3 Features Included In This Product Explained

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

Diverter

A diverter, specifically in bath-shower combos, redirects the water flow from the bathtub spout to the showerhead. You can activate it using the nozzle in the bath shower mixer tap.
Read more...

Combi-Boiler System

The showerhead or shower system is suitable for use with a Combi-Boiler System. This system heats cold water on demand, relying solely on mains pressure to move water around your home. These are suitable for mixer showers, as they provide hot water instantaneously and at the highest pressure.
