Duravit No.1 Floor Standing 370 x 480mm Rimless WC Pan And Seat

Duravit No.1 41840900A1 Details

The Duravit No.1 Floor Standing Rimless WC Pan and Seat showcase a washdown functionality. The deep bowl rimless design is a superior enhancement of the standard design to ensure a total absence of dust and germ traps. The rim-free bowl ensures it is hygienically so effective that cleaning is super easy. The washdown design ensures that every drop of water flushed from the toilet is used to clean the pan-thereby preventing re-flushing and saving water. You will also notice that its rim-free design keeps odours to a minimum. The product comes with a fabulous white finish.

The manufacturing code of this product is 41840900A1
Pack includes: Back to-wall WC pan and Toilet seat
It comes in a fabulous white alpin finish
Particularly rugged, scratch-resistant material with a high degree of hardness
Easy-clean and hygienic surface
Size [mm]: 370mm x 400mm [Width x Height]
Size [cm]: 37cm x 40cm [Width x Height]
Projection from wall: 480mm (48cm)
Shape: Round
Horizontal outlet
Hygienic washout flush without excessive spraying
With slow close for gentle, silent closure of the seat and lid
Open flushing rim with dynamic water flow
Perfectly hygienic flush results, even with small amounts of water
Particularly efficient, economical water consumption: Unified Water Label (UWL) class 1
CE Certified product
Download the Installation Instruction PDF File from the Additional Info Section
Refer to the technical drawing for complete size details
Five-year warranty from Duravit against manufacturing defects

Info / Size (mm)

Toilet
Width: 370 mm
Projection: 480 mm
Height: 400 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: No.1
⤷ Colour
: White Alpin
⤷ Weight in kg
: 24.4
⤷ Country of Origin
: Germany
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Ceramic
⤷ Theme
: Modern
⤷ Installation Type
: Floor Standing
⤷ Projection (Depth)
: 480
⤷ Rimless Bowl
: Yes
⤷ Width
: 370
⤷ Configuration
: Pan And Seat
⤷ Height
: 400

⤷ Seat Included
: Yes
⤷ Seat Type
: Soft-Close
⤷ Seat Finish
: High Gloss White
⤷ Fixings included
: Yes
⤷ Compliance/Approvals/Standard
: CE
⤷ Barcode
: 4053424680613
⤷ Bowl Shape
: Round
⤷ Seat Post Hole Centers
: 155
⤷ Front Of Bowl To Centre Of Seat Holes
: 430
⤷ Base width
: 245
⤷ Base Depth (projection)
: 350
⤷ Outlet Diameter
: 102
⤷ Base to centre of outlet
: 185

Additional Info & Downloads

Download the Installation Instruction Pdf File

Add-Ons

Concealed Cistern

The Duravit DuraSystem® concealed cistern is an installation element designed for the wet installation of wall-mounted toilets. Dual flush with adjustable volumes. Please Note: The image Shown Is For Illustration purposes only.

No Option Selected
OP-241093 - 400 x 150mm Dual Flush Concealed Cistern + £75.00

Flush Plate

The Duravit DuraSystem® flush plate is a mechanical actuator plate designed for wall-mounted toilets. It is compatible with the Beta 100 system and is intended for use with it only. Please Note: The image shown is for illustration purposes only.

No Option Selected
OP-241096 - Gloss Chrome Finish Dual Flush Plate + £30.30

Duravit No.1 Floor Standing 370 x 480mm Rimless WC Pan And Seat

£155.00

RRP: ~~£273.60~~

IN-STOCK

Delivery in 4 Working Days Approx.

QS Supplies

4 Features Included In This Product Explained

Horizontal Outlet

When the pan has piping at the back, inside the wall, it is called a horizontal outlet toilet or pan. As the cisterns are concealed or placed against the wall, most plumbing is hidden out of sight.

CE Certified Product

CE mark meets the prescribed safety, health and environmental protection requirements and all appropriate EU requirements. This mark is mandatory for products designed, made and sold in the European Economic Area.

Washdown Model

A washdown toilet uses the weight of the water and gravity to push out the toilet waste from the toilet bowl. The washdown toilet is designed with a short and wide trapway, so that waste can quickly enter the trapway using just the force of water from the tank. A washdown model includes a push-button flush and has a skirted design with a smaller water surface area and a short trapway and can easily handle heavy loads without getting clogged.

Open Rim Rimless Technology

This technology combines geometry, optimised flow and design to create a product with pure efficiency. The open-rim design enables innovative and efficient flushing while the water has a powerful flow with a horizontal arc, flushing out the entire inner bowl surface. The flushing rim design and bowl geometry offer a dynamic water flow and optimum flushing. It also prevents the build-up of germs and dirt, and residue.
