Armitage Shanks Compact Idealform Bath 1200 x 750mm 2 Tap Hole

Armitage Shanks Compact S125401 Details

If you want a good quality bathtub and your bathroom is small, do not despair as Armitage Shanks Compact Idealform Shower-tub is here to fulfil your wish. With a storage capacity of 190 litres, its compact design does well to help it fit in smaller sized areas. This product is made from reinforced acrylic, which meets the European Standard (EN 198:2008) that makes it appropriate for domestic use. This high quality bath carries a 25-year guarantee from its manufacturer.

Size [mm]: 1200mm x 750mm x 400mm [Length x Width x Depth]
Size [cm]: 120cm x 75cm x 40cm [Length x Width x Depth]
Manufacturing code of this product is S125401
Height: 530mm [53cm]
Pure white finish
Supplied with integrated feet
Suitable for both commercial and domestic use
The capacity of this product is 190 Litres
Comply to Constructed to EN 198:2008
It comes with a water-saving feature
Refer technical drawing from the technical tab
Idealform - [See Features Explained Section]
25 years of guarantee from the manufacturer against any manufacturing defects
Optional Product:
Universal Front panel
Tap, waste and overflow are not included

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Compact
⤷ Position of Drain
: Foot-end
⤷ Interior Shape
: Rounded Rectangular
⤷ Bath Type
: Standard
⤷ External Length
: 1183
⤷ External Width
: 743
⤷ Tub Depth
: 400
⤷ Feets Included
: Yes
⤷ Height Including Feet or Panel
: 530
⤷ Front Panel Included
: Sold Separately
⤷ Colour
: White
⤷ Internal Bottom Width
: 460
⤷ Internal Top Length
: 1060
⤷ Internal Top Width
: 660
⤷ Height of Rim
: 40

⤷ Distance Tub edge to centre of drain hole
: 240
⤷ Distance Top edge to centre of overflow hole
: 65
⤷ Diameter of overflow hole
: 44
⤷ Diameter of Drain hole
: 53
⤷ Rim Width
: 100, 40
⤷ Shape
: Rectangular
⤷ Capacity in litres
: 190
⤷ Country of Origin
: EU
⤷ Warranty/Guarantee
: 25 Years
⤷ Material
: Idealform Acrylic
⤷ No. of Bathers
: 1
⤷ Theme
: Modern
⤷ Waste Included
: Sold Separately
⤷ Barcode
: 5012001393109

Add-Ons

Bath Waste

A highly effective and practical 1-inch and 1/2-Inch combined bath waste! Please Note: The image shown is for illustration purposes only.

No Option Selected
OP-43035 - 1.5 Inch Combined Chain Waste And Overflow - S8830AA RECOMMENDED
+ £26.12
OP-171695 - Luxury Bath Pop-up Waste And Overflow - E1486AA + £162.79

Armitage Shanks Compact Idealform Bath 1200 x 750mm 2 Tap Hole

£414.74

RRP: ~~£721.79~~

STOCK AVAILABLITY: 3-4 Working Days Approx

QS Supplies

3 Features Included In This Product Explained

With / Without Overflow

An overflow is a small hole or opening at the upper part of a sink, basin, bidet or tub that drains away water upon reaching its level so that no water is spilt. When a basin or bath does not come with this design feature, it is called 'without-overflow' and will need a compatible drain.

Idealform

All Idealform baths are moulded from a high-quality reinforced cell-cast acrylic sheet that is warm to the touch and provides exceptional insulation. The sheet is heated and then vacuum formed into the desired bath shape. It is then fully reinforced with Glass Reinforced Polymer (GRP). A medium-density 15mm base board is positioned and encapsulated with extra Glass Reinforced Polymer (GRP). The bath is then cured, trimmed and drilled for tapholes or bath grips if required.

Optional: Front Panel

A front bath panel is a decorative accessory that is used to cover the front-facing side of a bathtub for a neat and polished look. It also conceals plumbing and framework and comes in different sizes, textures and materials.

Questions & Answers

Submit Your Questions 3 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Honor Asked :
Are the tap holes - punch outs?

Answered By QS Team

The tap holes, they are holes and not punch outs.

Was this answer helpful?

Nessa Asked :
Are the tap holes pre-drilled? Can the bath be supplied without tap holes?

Answered By QS Team

The Armitage Shanks Compact Bath bath is only available with pre-drilled tap holes, and cannot be purchased without them.

Was this answer helpful?

Robert Asked :
Hi, the 1200 Armitage Shanks sit/bath. Can you advise on shower screen sizes and if you supply these? Are they suitable for this bath? Swing and/or folding options. If you could quote me for the whole kit, bath and various screens, please?

Answered By QS Team

We do not have bath screens to fit this bath; many screens tend to be too big due to the size.

Was this answer helpful?
