Ideal Standard Tempo Cube Idealform White Double-Ended Bath

Ideal Standard Tempo E258301 Details

Ideal Standard Tempo Cube Idealform Double Ended Bath takes a simple everyday act of bathing to an unimaginably pleasant level. With a rectangular shape and ergonomic features that offer unique tranquillity, it is a must for those with busy lifestyles and needs complete relaxation. Made from rigid white finish Idealform it is sturdy, guaranteed for 25 years and offers excellent value for your money. When ordered from our online store, it comes at an astonishing price that makes it an excellent investment.

Available in 2 sizes: 1700mm, 1800mm
It comes in a white finish
Rectangular bath
Frequently used in hotels and residential applications
Supplied with no tap hole for maximum flexibility
Standards: Constructed to EN 198:2008. EN 14516
For complete size details, please refer technical drawing
Specification for 1700mm Bath
Weight: 23 kg
Size [mm]: 1695mm x 745mm x 410mm [Length x Width x Depth]
Size [cm]: 169.5cm x 74.5cm x 41cm [Length x Width x Depth]
Overall height: 550mm [55cm]
Water capacity: 200 litres
Specification for 1800mm Bath
Weight: 25.60 kg
Size [mm]: 1795mm x 795mm x 465mm [Length x Width x Depth]
Size [cm]: 179.5cm x 79.5cm x 46.5cm [Length x Width x Depth]
Overall height: 595mm [59.5cm]
Water capacity: 248 litres
Idealform - [See Features Explained Section]
Optional Products
Front and End Panels
Tap and waste shown in the image are not included

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Position of Drain
: Centered Waste
⤷ Bath Type
: Double-Ended
⤷ Interior Shape
: Rounded Rectangular
⤷ Range
: Tempo
⤷ External Length
: 1695
⤷ External Width
: 745
⤷ Tub Depth
: Internal - 410 External - 420
⤷ Height Including Feet or Panel
: 550
⤷ Front Panel Included
: Sold Separately
⤷ End Panel Included
: Sold Separately
⤷ Colour
: White
⤷ Internal Bottom Length
: 1030
⤷ Internal Bottom Width
: 295
⤷ Internal Top Length
: 1155
⤷ Internal Top Width
: 435
⤷ Height of Rim
: 40

⤷ Distance Tub edge to centre of drain hole
: 390, 410
⤷ Distance Top edge to centre of overflow hole
: 70
⤷ Diameter of overflow hole
: 44
⤷ Diameter of Drain hole
: 53
⤷ Rim Width
: 60, 65, 90
⤷ Weight in kg
: 23
⤷ Shape
: Rectangular
⤷ Capacity in litres
: 200
⤷ Country of Origin
: EU
⤷ Warranty/Guarantee
: 25 Years
⤷ Material
: Idealform Acrylic
⤷ No. of Bathers
: 2
⤷ Theme
: Modern
⤷ Waste Included
: Sold Separately
⤷ Barcode
: 5017830471646

Add-Ons

Bath Panel

White Finish Bath Panel. Please Note: The image shown is for illustration purposes only.

OP-57529 - Unilux 750mm End Panel - E319501 + £66.01
OP-57531 - 800mm End Panel - E260701 + £116.48
OP-57514 - Unilux 1700mm Front Panel - E319401 + £119.15
OP-57530 - 1800mm Front Panel - E260601 + £191.05

Compatible Bath Waste

Bath waste with overflow made using high quality material. Please note image is for illustration purpose only

No Option Selected
OP-171695 - Luxury Bath Pop-up Waste And Overflow - E1486AA + £162.79

'P' Trap

1.5-inch plastic P trap with 75mm seal - multi-purposes outlet suitable for plastic and BS copper pipe. Ideal for domestic and hotel use.

No Option Selected
OP-43041 - 1.5 Inch Plastic P Trap With 75mm Seal - MP Outlet For Plastic And BS Copper Pipe - S897067 + £32.08

Ideal Standard Tempo Cube Idealform White Double Ended Bath

£233.54

RRP: ~~£403.37~~

STOCK AVAILABLITY: 6 Working Days Approx

QS Supplies

3 Features Included In This Product Explained

With / Without Overflow

An overflow is a small hole or opening at the upper part of a sink, basin, bidet or tub that drains away water upon reaching its level so that no water is spilt. When a basin or bath does not come with this design feature, it is called 'without-overflow' and will need a compatible drain.

Idealform

All Idealform baths are moulded from a high-quality reinforced cell-cast acrylic sheet that is warm to the touch and provides exceptional insulation. The sheet is heated and then vacuum formed into the desired bath shape. It is then fully reinforced with Glass Reinforced Polymer (GRP). A medium-density 15mm base board is positioned and encapsulated with extra Glass Reinforced Polymer (GRP). The bath is then cured, trimmed and drilled for tapholes or bath grips if required.

Optional: Front Panel

A front bath panel is a decorative accessory that is used to cover the front-facing side of a bathtub for a neat and polished look. It also conceals plumbing and framework and comes in different sizes, textures and materials.
