Heritage Trinity Chrome Deck Mounted Bath Shower Mixer Tap With Handset

Heritage Trinity TTRCC02 Details

Combine the best traditional design with the latest technology in the Heritage Trinity Deck Mounted Bath Shower Mixer Tap with Shower Handset. The crisp lines and curvy details make the tap design exceptionally versatile, with dual crosshead levers extending straight up along the side.

The tap includes a handset with a 1500mm shower hose and comes in-built with ceramic disc cartridges that work with the handles to allow you to easily change the temperature of the water with more precision than usual. The high-quality brass resists rust and corrosion and carries a ten-year guarantee from the manufacturer against any manufacturing defects.

The manufacturing code of this product is TTRCC02
Traditional design
Includes handset with 1500mm [150cm] shower hose
Size [mm]: 230mm x 200mm x 300mm [Width x Depth x Height]
Size [cm]: 23cm x 20cm x 30cm [Width x Depth x Height]
Handset length: 250mm [25cm]
Deck mounted installation
Crosshead handle
The base to spout is 36mm [3.6cm]
The Centre of the inlet to the centre of the outlet is 150mm [15cm]
The minimum water pressure required is 0.2 bar, and the maximum water pressure of 5 bars
The flow rate of 14.4 litres/min at 0.2 bar water pressure
Maximum hot water temperature can be 65 degrees Celsius
Metal fixing nut included
Refer to the technical image for more technical details
Images shown are only for illustration purposes
Download the installation instruction and product data sheet PDF from the additional info section

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Rotating
⤷ Handle Position
: Left & Right
⤷ Tap Body Shape
: Round
⤷ Range
: Trinity
⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 10 Years
⤷ Material
: Brass
⤷ Theme
: Traditional
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 2
⤷ Spout type
: Fixed
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: 3/4 inch Long Stem Ceramic Disc Valves
⤷ Handle Material
: Brass

⤷ Base To Spout
: 36
⤷ Spout Reach
: 150
⤷ Overall Height
: 300
⤷ Width
: 230
⤷ Inlet Connections
: 3/4 inch BSP Connection
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Hose Included
: Yes
⤷ Hose Length
: 1500
⤷ Hand-Shower Included
: Yes
⤷ Shower Handset Material
: Brass
⤷ Flow Rates (l/min)
: 0.2 Bar - 14.4 l/min
⤷ Handle Style
: Crosshead
⤷ Barcode
: 5055138575567
⤷ Product Type
: Bath Shower Mixer Tap

Additional Info & Downloads

Download the Installation Instruction Pdf File Download the Product Data Sheet Pdf File

Heritage Trinity Chrome Deck Mounted Bath Shower Mixer Tap With Handset

£217.07

RRP: ~~£365.00~~

STOCK AVAILABLITY: 6 Working Days Approx

QS Supplies

3 Features Included In This Product Explained

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

Diverter

A diverter, specifically in bath-shower combos, redirects the water flow from the bathtub spout to the showerhead. You can activate it using the nozzle in the bath shower mixer tap.
Read more...
