Heritage Trinity Chrome Thermostatic Shower Valve With Shower Head And Riser Rail Kit

Heritage Trinity STRCDUAL01 Details

Make showering a more luxurious experience every time you step beneath the Heritage Trinity Thermostatic Shower Valve. The product includes a shower valve, shower head, shower arm, rise riser rail kit, hand shower, hose and wall outlet. The thermostatic mechanism allows you to control the water temperature and flow with great precision.

This product is designed for use with a minimum 0.2 of 0.2 bar and a maximum of 5 bar pressure. This is an assortment made for the entire family's comfort. This complete pack is designed to comply with stringent industry-building norms and is manufactured to the highest standards.

The manufacturing code of this product is STRCDUAL01
It comes in a chrome finish
Fully serviceable from the front
Images shown are only for illustration purposes
Refer to the technical image for more technical details
Download installation instructions and product data sheet PDF from the additional info section
Specification for shower valve:
Size [mm]: 165mm x 130mm x 255mm [Width x Depth x Height]
Size [cm]: 16.5cm x 13cm x 25.5cm [Width x Depth x Height]
Inlet centres: 150mm [15cm]
Required only 35mm [3.5cm] deep cavity space
Integral 2 outlet diverter
The inlet and outlet connection of 15mmcompression
Temperature is set to 42-53 degrees by the brand, which will maintain a safe temperature even in the event of cold water supply failure
Working pressure of minimum 0.2 bar and maximum of 5 bars
Maximum hot water temperature can be 65 degrees Celcius
Specification for shower arm and head:
Arm length: 360mm [36cm]
Shower Head Size [mm]: 126mm x 200mm [Height x Diameter]
Shower Head Size [cm]: 12.6cm x 20cm [Height x Diameter]
Arm connection of G 1/2 inch Male
Shower head connection of G 1/2 inch Female
Specification for wall outlet:
Size [mm]: 77mm x 62mm x 77mm [Width x Depth x Height]
Size [cm]: 7.7cm x 6.2cm x 7.7cm [Width x Depth x Height]
Inlet connection of G 1/2 inch
Specification for riser rail kit:
Riser rail kit length: 710mm [71cm]
Single shower function
1500mm [150cm] shower hose

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Brass
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Thermostatic Cartridge
⤷ Inlet Centres
: 150
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Hose Included
: Yes
⤷ Hose Length
: 1500
⤷ Flow Rates (l/min)
: 0.2 Bar - 8.5, 0.5 Bar - 13.4, 1 Bar - 19, 2 Bars - 26.9, 3 Bars - 32.9, 5 Bars - 42.5
⤷ Temperature Control
: Thermostatic

⤷ Diverter Included
: Yes
⤷ Product Type
: Thermostatic Shower
⤷ Showerhead Type
: Fixed
⤷ Showerhead Finish
: Chrome
⤷ Riser Rail & Kit Finish
: Chrome
⤷ Handset Included
: Yes
⤷ Spray Patterns (Shower Handset)
: Single
⤷ Spray Patterns (Shower Head)
: Single
⤷ Shower Head Included
: Yes
⤷ Shower Head Size
: 200
⤷ Rail Length
: 710
