Villeroy And Boch O.Novo Compact Close Coupled Floor Standing DirectFlush Rimless WC Pan

O.Novo 5689R001 Details

Villeroy and Boch O.Novo Compact Close Coupled Floor Standing DirectFlush Rimless WC Pan makes a remarkable statement while offering an efficient and comfortable design. The close coupled format where the tank sits directly on the back of the toilet pan is an excellent space saver.

The toilet seat and cistern are available for purchase separately. The floor-standing pan is skillfully crafted from the best sanitary ceramic, making it tough and long-lasting. The unit is carefully made to provide absolute comfort within the home or office. Its profile gives it a more decadent and more elegant look suitable for full family use.

Manufacturing code: 5689R001
It comes in a White Alpin finish
Size in [mm]: 360mm x 400mm [Width x Height]
Size in [cm]: 36cm x 40cm [Width x Height]
Floor-standing installation
Scope of delivery: 1 x washdown rimless toilet, 1 x fastening set
Suitable for: Mounted cistern
Cistern And Toilet Seat available [See Option Below]
Flush type: Washdown toilet
Flush volume: 3/4L,5L
Outlet: Horizontal
Leed: 4
Weight: 21kg
Refer to the technical diagram for the complete technical dimensions
Download installation instructions and product data sheet from the additional info section
DirectFlush Features:
DirectFlush WCs can be cleaned quickly and thoroughly – for quintessential hygiene. It can be hard to clean under the rim of a standard toilet as the toilet brush and cleaning agent do not reach everywhere
Hygiene:
Easy care and immaculate cleaning
thanks to the rimless design
The total interior of the bowl is completely flushed
Precise, the splash-free flow of water in the toilet right up to the level directly below the rim
Design:
Attractive and timeless design
It can easily incorporate into any bathroom
Invisible fixation system for the ceramics collection Subway 2.0
Efficiency:
Ideal water flow for maximum flushing effect
Water-saving, with a flushing volume of only 3 or 4.5 litres
Cistern And Toilet Seat are not included

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: O.Novo
⤷ Toilet Design
: Open-Back
⤷ Colour
: White-Alpin
⤷ Weight in kg
: 21
⤷ Warranty/Guarantee
: 2 Years
⤷ Material
: Ceramic
⤷ Theme
: Modern
⤷ Installation Type
: Floor Standing
⤷ Water Saving
: Yes
⤷ Pan Width
: 360
⤷ Pan Height
: 400

⤷ Projection (Depth)
: 605
⤷ Rimless Bowl
: Yes
⤷ Cistern Included
: Sold Separately
⤷ Outlet
: Horizontal
⤷ Configuration
: WC Pan Only
⤷ Compact Design
: Yes
⤷ Seat Included
: Sold Separately
⤷ Barcode
: 4051202487249
⤷ Bowl Shape
: Elongated
⤷ Outlet Diameter
: 102
⤷ Base to centre of outlet
: 180

Additional Info & Downloads

Download the Installation Instruction Pdf File Download the Technical Data Sheet Pdf File

Add-Ons

Compatible Cistern

Compatible Cistern Available. The image is for illustration purpose only.

No Option Selected
OP-225771 - Water Inlet From The Sides White Alpin Cistern + £160.25
OP-225770 - Bottom Water Inlet White Alpin Cistern + £160.25

Compatible Seat

Compatible Seat And Cover Available As An Optional. Note: Image Is For Illustration Purpose Only.

No Option Selected
OP-225753 - Duroplast Soft-Closing Quick Release Hinge Toilet Seat And Cover + £84.71

Villeroy And Boch O.Novo Compact Close Coupled Floor Standing DirectFlush Rimless WC Pan

£243.43

RRP: ~~£331.20~~

IN-STOCK

Delivery in 3 Working Days Approx.

QS Supplies

6 Features Included In This Product Explained

Optional: Soft-Close Seat

Soft-closing seats are a new alternative to classic toilet seats. Their modern design allows them to close slowly, while their controlled manner of closing does not require you to assist them. It also shuts automatically, allowing it to come down at a pace that does not make much noise.

Optional: Quick Release Toilet Seat

The hinge on a regular toilet seat makes it challenging to clean in some areas. As a result, some areas build up with hairs, grime, and dirt over time. Fortunately, the invention of a quick-release toilet seat means you can keep your entire toilet clean. The hinge mechanism of these toilets allows you to remove the seat entirely, making it easier to wash the areas it covers on the toilet itself.

Horizontal Outlet

When the pan has piping at the back, inside the wall, it is called a horizontal outlet toilet or pan. As the cisterns are concealed or placed against the wall, most plumbing is hidden out of sight.

Rimless

A rimless toilet does not have a brim at its edge, from which the water usually flows when you flush. Instead of flowing from the top, such toilets shoot water towards its edge and around it, allowing no missing spots with filth remaining after a flush. These toilets also remove any spaces for germs to hide and breed, providing a hygienic alternative for your bathroom.

Optional: Duroplast

It is an artificial material made with a polymer blend invented in Germany. This durable and long-lasting material is most widely used in the manufacture of toilet seats and can also resist harsh cleaners.

DirectFlush

WCs from Villeroy And Boch are designed to maximise toilet hygiene. It does away with the hard-to-reach rimmed standard toilet and works to clean out the inner bowl without splashing completely. It is efficient, stylish, and saves water with its dual volume mechanism of 3 or 4.5 litres. The Subway 2.0 rimless toilets also fit neatly with the Invisible fixation system.
