Ideal Standard Ceratherm T125 Exposed Thermostatic Bath Shower Mixer

Ceratherm A7593AA Details

Ideal Standard Ceratherm T125 Exposed Thermostatic Deck Mounted Bath Shower Mixer Tap offers stylish, sleek looks to complement modern bathrooms that demand attractive looks and functionality. It has a convenient bar design moulded from solid brass. It also has a durable metal construction that will last for ages without giving out over time.

It offers the perfect finishing touch to the bath, with a sleek chrome finish that goes well with virtually any decor. It is also worth noting that this mixer has thermostatic control for safe water temperature, which stays near constant. A wall-mounted design with dual control knobs, it will work flawlessly in high water pressure.

Chrome plated finish
Deck mounted installation
The manufacturing code of this product is A7593AA
Complies with EN1111
Width: 304mm [30.4cm]
Inlet center: 150mm [15cm]
Base to spout: 79mm [7.9cm]
Centre of the inlet to the centre of the outlet: 157mm [15.7cm]
Dual control shower mixer valve
Weight: 2.82 kg
For complete size details, refer to the technical drawing
Download the Installation Instruction PDF from the additional tab
Features:-
Includes Precitherm cartridge for precise temperature control with adjustable temperature limit stop
Max temperature limiter function that can be set to avoid accidental scalding
Minimum recommended water pressure: 0.5 bar
Suitable for high water pressure systems
Minimalistic cylindrical design with 2-in-1 pin handle for easy grip and override button
Thermostatic cartridge with adjustable permanent hot water stop
1/2 inch shower outlet from below with integrated non-return valve
SmartShine® Finishing allows our chrome to last longer. It makes our taps easy to clean and easy to maintain

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Material
: Brass
⤷ Spout type
: Fixed
⤷ Handle Material
: Brass
⤷ Base To Spout
: 79
⤷ Spout Reach
: 157
⤷ Max. Deck Thickness
: 33

⤷ Inlet Connections
: G 1/2"
⤷ Minimum Operating Pressure (Bar)
: 0.5
⤷ Water Saving
: Yes
⤷ Handle Style
: Lever
⤷ WRAS Approved
: Yes
⤷ Compliance/Approvals/Standard
: EN1111

Additional Info & Downloads

Download the Installation Instruction Pdf File

Ideal Standard Ceratherm T125 Exposed Thermostatic Bath Shower Mixer

£330.04

RRP: ~~£507.74~~

STOCK AVAILABLITY: 6 Working Days Approx

QS Supplies

2 Features Included In This Product Explained

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
Read more...

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.
