Delabie Fino 290 x 325mm Stainless Steel Rimless Urinal

Delabie Fino 135710 Details

Delabie Fino Stainless Steel Rimless Urinal will help create a cleaner-looking urinal space in your commercial or residential bathroom. This urinal features sleek lines and curves, giving it a more contemporary appearance than standard urinals.

The product is made of top-quality, durable stainless steel that will outlast many years of use. The Polished Satin or Matte Black finishes give an extraordinary look to fit luxury or prime bathroom settings. The design is rimless and easy to clean, with a concealed trap to prevent odours from escaping.

Stainless steel thickness: 1.2mm (0.12cm)
Size [mm]: 290mm x 325mm x 420mm [Width x Depth x Height]
Size [cm]: 29cm x 32.5cm x 42cm [Width x Depth x Height]
Rear water inlet (recessed)
Recessed or exposed horizontal waste outlet
Concealed trap
Quick and easy to install
Supplied with a 1 1/2" P trap
Supplied with fixing elements
Weight: 3.5kg
Complies with European standard EN 13407 for a 2-litre flush
Refer to the technical drawing for complete size details

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Fino
⤷ Colour
: Polished Satin
⤷ Warranty/Guarantee
: 10 Years
⤷ Material
: Stainless Steel
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted

⤷ Projection (Depth)
: 325
⤷ Width
: 290
⤷ Outlet
: Horizontal
⤷ Height
: 420
⤷ Fixing Holes Centre
: 110
⤷ Barcode
: 3456330175463

Delabie Fino 290 x 325mm Stainless Steel Rimless Urinal

£366.01

RRP: ~~£540.36~~

STOCK AVAILABLITY: 6 Working Days Approx

QS Supplies

3 Features Included In This Product Explained

Rimless

A rimless toilet does not have a brim at its edge, from which the water usually flows when you flush. Instead of flowing from the top, such toilets shoot water towards its edge and around it, allowing no missing spots with filth remaining after a flush. These toilets also remove any spaces for germs to hide and breed, providing a hygienic alternative for your bathroom.

Stainless Steel Material

Stainless Steel is an iron alloy with anti-rust and anti-corrosive properties, unlike iron. Along with other metal alloys, it contains a minimum of 10.5% of chromium and less than 1.2% of carbon. This robust, hygienic, hard-wearing base material is popular in the construction of bathroom products.

CE Certified Product

CE mark meets the prescribed safety, health and environmental protection requirements and all appropriate EU requirements. This mark is mandatory for products designed, made and sold in the European Economic Area.

Questions & Answers

Submit Your Questions 1 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

STEPHEN Asked :
Hi Guys, I need to purchase three stainless steel urinals. I just need a bit of technical help first to see if they're compatible. Can three of these urinals run off a water tank, or have they got to be cut directly into the main feed for optimum pressure? I know the Chinese ones with spreaders are fine for tanks, but I'm not sure about these stainless ones. Ideally, I would like to run three of them off a tank with a cisterniser.

Answered By QS Team

The three stainless steel urinals can be run using a water tank. The urinals themselves don't need high pressure; they just need a 2-litre flush. The pressure matters more for the flushing system you use, and since you're not using a direct flush valve that requires specific pressure, it's not an issue. Also, these urinals meet the BS EN 13407 standard, which is set for a 2-litre flush.
