QS Basics VOX 500mm Wide Straight Steel Towel Rail

QS Basics VOX QSB-2674.JP Details

QS Basics VOX 500mm Wide Straight Steel Towel Rail could end up being your best buy this year. And why not? It is high-quality and supreme efficiency rolled into one. This straight-design model in mild steel is not only easy to use but also to install.

Its suitable for central heating, dual fuel and an electric system. But the best part is QS Supplies is offering it to you at a bargain price. Time to make a wise investment, what say you? This heated towel rail comes in several finish choices and is a must-buy.

Key Features

✔Available in 4 finishes: Chrome, Matt Black, Brushed Black and Brushed Brass
✔Product Composition: mild steel
✔2 year guarantee from the manufacturer

Available in 3 different heights: 800mm, 1200mm and 1600mm
Size [mm]: 500mm x 75mm [Width x Depth]
Size [cm]: 50cm x 7.5cm [Width x Depth]
Suitable for use as dual fuel, central heating, and electric system
Wall mounted installation
Details for 800mm Height
Recommended Element: 200w
Bars: 13
BTU (Heat Output): 859
Pipe Centre: 450mm (45cm)
Liquid capacity for Electric Only: 3.7L (Glycol: 0.9L, Water: 2.8L)
Details for 1200mm Height
Recommended Element: 400w
Bars: 21
BTU (Heat Output): 1357
Pipe Centre: 450mm (45cm)
Liquid capacity for Electric Only: 5.9L (Glycol: 1.5L, Water: 4.4L)
Details for 1600mm Height
Recommended Element: 600w
Bars: 31
BTU (Heat Output): 1947
Pipe Centre: 450mm (45cm)
Liquid capacity for Electric Only: 8.4L (Glycol: 2.1L, Water: 6.3L)
Refer to the technical drawing for complete size details
For use as electric only, the correct amount of glycol should be added - not included
Valve and Heating elements are not included - sold separately

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: VOX
⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 2 Years
⤷ Material
: Mild Steel
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Projection (Depth)
: 75
⤷ Width
: 500
⤷ Height
: 800

⤷ Orientation
: Vertical
⤷ Barcode
: 5057199973689
⤷ BTU Output
: 859
⤷ No. Of Bars
: 13
⤷ Tapping / Pipe Centres
: 450
⤷ Valves Included
: Sold Separately
⤷ Tube Diameter
: 25
⤷ Heating Element Included
: Sold Separately

Additional Info & Downloads

Download the Installation Instruction For Electric Only Pdf File

Technical Images

QS Basics VOX 500mm Wide Straight Steel Towel Rail

Add-Ons

Optinal Pipe And Flanges

pipes and flanges are designed to replace visible copper pipes. Please Note: The image is for illustration purpose only.

No Option Selected
OP-230932 - Set Of Chrome Pipe And Flanges For Radiator Valves + £19.28
OP-230933 - Set Of Brushed Brass Pipe And Flanges For Radiator Valves + £19.28
OP-230934 - Set Of Brushed Black Pipe And Flanges For Radiator Valves + £19.28
OP-230935 - Set Of Matt Black Pipe And Flanges For Radiator Valves + £19.28

Blanking Plug

Strong and durable blanking plug for its radiator in different finishes available as an optional. Select the desire of your choice from the option given below. please note: image shown is for illustration purpose only.

No Option Selected
OP-230938 - Radiator Blanking Plug - Chrome + £14.03
OP-230939 - Radiator Blanking Plug - Brushed Brass + £14.03
OP-230940 - Radiator Blanking Plug - Brushed Black + £14.03

£94.25

RRP: ~~£145.00~~

STOCK AVAILABLITY: 6 Working Days Approx

QS Supplies

4 Features Included In This Product Explained

BTU Output

It is the short form of a British thermal unit (BTU or Btu) and is defined as the amount of heat required to raise the temperature of one pound of water by one degree Fahrenheit. It is a standard unit against which radiator efficiency is measured.
Read more...

Dual Fuel

These radiators or towel warmers can run on a conventional gas-powered central heating system or via your mains electrical supply. You can choose whether or not you want your radiator or towel warmer to come on independently of your central heating system, which is especially useful in summer. These radiators are compatible with heating and hot water, whether the system is open (direct) or closed (indirect).
Read more...

Optional: Radiator Valve

Radiator valves help control how much hot water enters and leave it, and the flow of water controls how much heat the radiator generates. These are usually found at the radiator's bottom left, and right corners, where the water pipes enter and exit, or can also be present at the bottom near the centre.
Read more...

Mild Steel

Mild Steel is the most common radiator material. It is inexpensive, available in a variety of designs and finishes, lightweight and durable.
