Nuie Traditional Mono Kitchen Sink Mixer Tap

Nuie KB303 Details

Transform your bathroom from ordinary into awesome with this Kitchen Sink Mixer Tap from the Traditional range of Nuie. This one-piece product comes to you in brushed nickel, brushed brass and chrome finish with a sleek traditional cross-head handle design.

The main attraction of this product is the tall curving spout. Manufactured using high-quality material, it has been designed to appeal to modern, contemporary aesthetic tastes. This sleek product works using the latest quarter-turn ceramic disc valves for uninterrupted, drip-free performance.

Cartridge, mounting hardware, tap tails and fixing Included
Overall size [mm]: 210mm x 320mm [Width x Height]
Overall size [cm]: 21cm x 32cm [Width x Height]
Base to spout: 200mm (20cm)
Centre of the inlet to centre of outlet: 165mm (16.5cm)
Pipe size: 15mm (1.5cm) (1/2inch Bsp)
A high-end finishing touch to any kitchen
Installation type: Deck mounted
Cartridge material: Brass
Ceramic disc technology for long life and smooth operation
Suitable for medium-pressure water system
Requires a minimum of 0.5 bar of water pressure
Flow Rates: 0.1 bar - 4.2, 0.5 bar - 8.3, 1 bar - 12, 2 bar - 16.8, 3 bar - 20.6
Download the Customer Data Sheet and Installation Instruction PDF File from the Additional Info Section
Refer to the technical drawing for more technical specifications

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Handle Position
: Left | Right
⤷ Tap Body Shape
: Round
⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 3 Years
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 1
⤷ Spout type
: Fixed
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: 1/4 Turn Ceramic Disc
⤷ Base To Spout
: 220

⤷ Spout Reach
: 203
⤷ Overall Height
: 320
⤷ Width
: 210
⤷ Inlet Connections
: 15mm (1/2Inch Bsp)
⤷ Minimum Operating Pressure (Bar)
: 0.5
⤷ Flow Rates (l/min)
: 0.1 bar - 4.2 | 0.5 bar - 8.3 | 1 bar - 12 | 2 bar - 16.8 | 3 bar - 20.6
⤷ Handle Style
: Crosshead
⤷ Waste Included
: Sold Separately
⤷ Barcode
: 5056678401163
⤷ Product Type
: Kitchen Sink Mixer Tap
⤷ Tails
: Yes

Additional Info & Downloads

Download the Customer Data Sheet Pdf File Download the Installation Instruction Pdf File

Nuie Traditional Mono Kitchen Sink Mixer Tap

£67.64

RRP: ~~£135.00~~

STOCK AVAILABLITY: 6 Working Days Approx

QS Supplies

3 Features Included In This Product Explained

Monobloc Tap

A Monobloc/Mono tap has a single control lever that adjusts the mix of hot and cold water supplies and the flow rate. A mixer tap has two separate controls for hot and cold water. Both work equally well, and your choice will come down to aesthetics and how many tap holes your sink has. Monobloc taps are a neater solution and more modern in appearance.

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
Read more...

Medium Water Pressure

Water systems operating at a pressure between 0.5 and 0.9 bar are considered medium pressure. Products usually come labelled if they are suitable for use in medium pressure.

Nuie Traditional Mono Kitchen Sink Mixer Tap

MFC Code: KB303

Nuie KB303 Details

Technical Specifications

Additional Info & Downloads

3 Features Included In This Product Explained

Reviews & Ratings
