IS Ceraplan Single Lever High Tubular Spout Kitchen Mixer Tap

Ideal Standard Ceraplan BD336AA Details

Ideal Standard Ceraplan Single Lever High Tubular Spout Kitchen Mixer Tap.

The manufacturing code of this product is BD336AA
Size [mm]: 234mm x 312mm [Depth x Height]
Size [cm]: 23.4cm x 31.2cm [Depth x Height]
The centre of the inlet to the centre of the outlet is 200mm [20cm]
Base to spout: 209mm [20.9cm]
Designed by Palomba Serafini Associati
360° Swivel spout
Flexible tails to simplify and speed up installation
38mm ceramic disc cartridge
For complete size details, please refer to the technical drawing
Download the Installation Instruction PDF file from the Additional Info Section
Specification Features:
Flow rate: 5 litres per minute at 3 bar pressure
Suitable for high water pressure systems
FirmaFlow ceramic cartridges fitted for a long, high-performance lifespan are tested to 500,000 cycles, equivalent to 10-15 years of daily use.
Pre-fitted 5 litres per minute eco flow regulators to save water
EASY FIX - Patented feature for installer's benefits, making it easier and quicker to tighten than conventional fixings
Our BlueStart Technology saves energy by delivering cold water when the tap is in the central position. Hot water is only used when actively selected, resulting in up to 50% energy savings
Max temperature limiter function that can be set to avoid accidental scalding
Light Move - Enjoy a great experience thanks to the light, smooth cartridge, which ensures that the water flow is just proper for you

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Rotating
⤷ Range
: Ceraplan
⤷ Handle Position
: Right
⤷ Tap Body Shape
: Square
⤷ Colour
: Chrome
⤷ Country of Origin
: EU
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 1
⤷ Spout type
: Swivel
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Ceramic Cartridge
⤷ Handle Material
: Brass

⤷ Spout Swivel
: Yes
⤷ Base To Spout
: 209
⤷ Spout Reach
: 200
⤷ Overall Height
: 312
⤷ Max. Deck Thickness
: 40
⤷ Inlet Connections
: G 3/8"
⤷ Minimum Operating Pressure (Bar)
: 3
⤷ Flow Rates (l/min)
: 3 Bar - 5 Ltr
⤷ Handle Style
: Lever
⤷ Deck Mount Drill Hole Diameter
: 35
⤷ Spout Flow
: Single
⤷ Flow Regulator Included
: Yes
⤷ Barcode
: 3800861104971
⤷ Product Type
: Kitchen Mixer Tap
⤷ Tails
: Flexible

Additional Info & Downloads

Download the Installation Instruction Pdf File Download the Spare Part List Pdf File Download the Flow Rate Pdf File Download the Declaration Of Conformity Pdf File

IS Ceraplan Single-Lever High Tubular Spout Kitchen Mixer Tap

£157.33

RRP: ~~£269.44~~

STOCK AVAILABLITY: 6 Working Days Approx

QS Supplies

6 Features Included In This Product Explained

Swivel-Spout

The respective apparatus is engineered to move sideways or at certain angles, which helps the spout cover a greater area than would be possible in a fixed position.

Flexible Tail Pipes

Flexible Tails, or "Flexi" Tails, are one of the easiest methods to connect the plumbing pipework to the tap fitting. Mixers generally have two tails, one for the hot water supply and the other for the cold. These tailpipes consist of rubber inside a braided metal and come in many sizes.

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

FirmaFlow Ceramic Cartridge

The firmaFlow ceramic disc cartridge uses Click Technology with a mechanical stop to limit the tap water flow at the basin to just the amount needed to wash hands. It maintains flow consistency, reduces use by up to 50%, and offers the utmost temperature precision and safety. It can fine-tune the temperature between 34°C and 42°C. This cartridge has almost double the lifespan as the industry standard lasts– 500,000 cycles, compared to 300,000 cycles. It has a high hot water resistance of greater than 95°C.

Easy-Fix Fixation System

With the easy-fix system, tap assembly is fast and easy. It is so simple that the tap can be assembled with one hand with the rubber membrane on the "screw-nut". Using the sealing component, you can secure the tap in the best possible way on the porcelain and get the perfect sealing.

Cold start BlueStart® Technology

Unique Cold Start BlueStart® technology helps you save water, energy and money by delivering cold water only when the tap handle is in the centre position. This clever technology prevents water from heating up unnecessarily when you turn on the tap.
