Joseph Miles Windsor Thermostatic Shower Set With Valve Body And Outlet Elbow

Finishes: Chrome, Matt Black, Brushed Brass

£133.20

RRP: £440.00

STOCK AVAILABLITY:

6 Working Days Approx.

Not Yet Rated No Rating

Shipping: FREE* Check Postcodes

Select Finish
You've selected: OP-232571 - Chrome
Key Features
  • Available in 3 finishes
  • WRAS approved
  • Manufactured using brass material
SKU Code: QS-V111209

MFC Code: JMQS

Windsor JMQS Details

Joseph Miles Windsor Thermostatic Shower Set With Valve Body And Outlet Elbow shows what great showering is all about. The Thermostatic Shower Valve, which easily mounts to the wall, is manufactured using solid brass. It comes with a handset and hose and has a drool-worthy traditional format.

The handset offers three spray patterns you can change for your showering needs. It will work flawlessly under high water pressure, so it is best to check your water pressure system before buying this model. For further guidelines, read our article Know your homes water pressure. Excellent performance and extreme durability—this product is rare but a perfect combination of both qualities.

  • Inlet connection: G1/2 Inch
  • Refer to the technical diagram for complete technical dimensions
  • Download the product installation instruction PDF from the additional info section
  • Details Of Thermostatic Valve:
  • Size In [mm]: 288mm x 132mm x 66mm [Width x Depth x Height]
  • Size In [cm]: 28.8cm x 13.2cm x 6.6cm [Width x Depth x Height]
  • Weight: 2.64kg
  • Maximum Static Pressure: 10 Bar
  • Flow Pressure, Hot and Cold: 0.5 Bar to 5 Bar
  • Hot Supply Temperature: 55°C to 65°C
  • Cold Supply Temperature: Equal to or less than 25°
  • Details Of Shower Set:
  • Size In [mm]: 100mm x 140.8mm x 698mm [Width x Depth x Height]
  • Size In [cm]: 10cm x 14.08cm x 69.8cm [Width x Depth x Height]
  • Weight 0.87kg
  • The handset features 3 spray mode
  • Hose Length: 1500mm - (150cm)
  • Size of shower handset In [mm]: Ø100mm x 247.8mm [Diameter x Height]
  • Size of shower handset In [cm]: Ø10cm x 24.78cm [Diameter x Height]
  • Suitable for high water pressure system
  • Required minimum work pressure is 1 bar, maximum work pressure is 5 bar
  • Note: If the mains pressure is over 5 bar, then a flow regulator should be fitted

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Colour
  • : Chrome
  • ⤷ Material
  • : Brass
  • ⤷ Valve Included
  • : Yes
  • ⤷ Minimum Operating Pressure (Bar)
  • : 0.5
  • ⤷ Hose Included
  • : Yes
  • ⤷ Hose Length
  • : 1500
  • ⤷ Temperature Control
  • : Thermostatic
  • ⤷ Compliance/Approvals/Standard
  • : WRAS
  • ⤷ Product Type
  • : Shower Set
  • ⤷ Plumbing System Compatibility
  • : Exposed
  • ⤷ Riser Rail & Kit Finish
  • : Chrome
  • ⤷ Handset Included
  • : Yes
  • ⤷ Spray Patterns (Shower Handset)
  • : 3 Modes
  • ⤷ Valve Size
  • : 288mm W x 132mm D x 66mm H
  • ⤷ Rail Length
  • : 698

Additional Info & Downloads

Download PDFDownload the Installation Instructions Of Valve Pdf File Download PDFDownload the Installation Instructions Of Rail Kit Pdf File

£133.20
RRP: £440.00
STOCK AVAILABLITY: 6 Working Days Approx
QS Supplies
Selected Finish: Chrome

3 Features Included In This Product Explained

Thermostatic Control

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

WRAS Approved Product

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws.
Read more...

High Water Pressure

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.
