Geberit Sigma10 Main Operated Single Flush Plate For Pull-Down Rail And Radio

Geberit Sigma10 Main Operated Single Flush Plate for Pull-Down Rail and Radio provides a modern and effective flushing solution with concealed cisterns. It is designed for manual remote flush actuation of Sigma concealed cisterns using pull-down rails with an RF-controlled button. It can be controlled via the Geberit Control App for convenience.

Available in a rectangular format, it is durably made out of stainless steel. The flush is manually activated with a low-noise lifting mechanism when the button is released. The minimalist form of these units is matched by the minimalist design scheme.

• The manufacturing code of this product is 115.867.SN.6
• Size [mm]: 246mm x 15mm x 164mm [Width x Thickness x Height]
• Size [cm]: 24.6cm x 1.5cm x 16.4cm [Width x Thickness x Height]
• Plate and button: brushed, easy-to-clean coated and design rings: polished
• Material: Stainless steel
• Suitable for manual remote flush actuation of Sigma concealed cisterns 12cm using pull-down rails with RF-controlled button
• For solid and drywall construction
• Suitable for less-abled installation
• Compatible to use with Sigma concealed cisterns 12cm
• Not suitable for use with Geberit inserts for in-cistern block
• Flush actuation using pull-down rail, wireless, radio
• Single flush can be triggered via a flush plate
• Power supply via external power supply unit
• Transformation of mains voltage to extra-low voltage 12V DC
• Operation with extra-low voltage, no mains voltage in a cistern
• With push-fit connection with cross-polarity protection
• Adjustable interval flush - can be preset
• Wired networkable with Geberit gateway via GEBUS converter
• Wirelessly connectable with Geberit Gateway via Bluetooth
• Compatible with Geberit Connect
• Electrical lifting device and self-calibrating
• Protection degree: IP45 rated
• Nominal voltage: 85-240V AC
• Mains frequency: 50-60 Hz
• Operating voltage: 12V DC
• Power consumption: ≤ 4 W
• Power consumption standby: 0.15 W
• Radio frequency: 868.4 MHz
• Radio frequency distance: 10 m
• Interval flush, adjustment range: 1-168 h
• Interval flush, factory setting: 24 h
• Interval flush time, adjustment range: 1-200s
• Interval flush time, factory setting: 5s
• Refer technical drawing for more details
• Scope Of Delivery:
• Sigma10 flush plate
• Mounting frame
• Protection plate
• Actuator rod
• Support block with servomotor and lifting device, premounted
• Control electronics with a radio receiver
• Fastening material
