Duravit Qatego Single Ended Built-In Sanitary Acrylic Whirlpool Bath

Duravit Qatego 760610000AS0000 Details

Duravit Qatego Single Ended Built-in Sanitary Acrylic Whirlpool Bath is defined by a rectangular form and inner soft lines, which make it spacious and visually pleasing. The whirlpool system with jets will help you relax your tired muscles and relieve tension by giving you a gentle massage.

This is a single-ended bath, which is extremely comfortable with a sloping back, and enables you to recline in comfort. Maximise the benefits of the whirlpool by resting your back and submerging completely. This unit screams luxury at its best.

Key Features

✔Type of installation: Built in
✔Constructed using sanitary acrylic
✔Designed by Studio F. A. Porsche
✔Five-year warranty from Duravit against manufacturing defects

Available in 5 different sizes - Optional]
Whirlpool System - Air-System, Jet-System And Combi-System E - [Optional]
Shape: Rectangular
Single-ended bath
One backrest slope for complete submerging in water
Depth: Internal 460mm (46cm) and External 480mm (48cm)
It comes in a White Alpin finish
Refer technical drawing for more technical specification
Download Customer datasheet and Installation Instruction PDF from the Additional Info section
Available optional product
Quadroval Waste and Overflow with Tub Filler
Bathtub Anchor
Rubber Profile
Tub Heating
Features of Air-System
12 Drilled floor air jets (Standard)
Support Frame
Waste and Overflow included
Control Element - Piezo floor jets
Features of Jet-System
6 flat, Adjustable Standard jets (Mixture of Air and water)
Support Frame
Waste and Overflow included
Features of Combi-System E
Standard 6 flat, adjustable side jets (Mixture of Air and water)
Standard 12 flat, adjustable floor jets (Air)
Standard 4 flat, adjustable back jets (Mixture of Air and water)
2 Spot, LED white light
Standard 2 flat, adjustable foot jets (Mixture of Air and water)
Waste and Overflow included
Support Frame
Diverter
Pump performance can be concentrated to foot or back jets
Control panel with chromed brass frame and blue backlit symbols. By pressing the desired symbol, the functions starts and the symbol is blue backlit
For Water Capacity of Bath Please refer a Chart in Product Variations Info & MFC Code Section
Images Shown is for illustration Purpose only

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Qatego
⤷ Position of Drain
: Waste at Foot End
⤷ Bath Type
: Whirlpool
⤷ Interior Shape
: Rounded Rectangular
⤷ Coating
: Standard
⤷ External Length
: 1600
⤷ External Width
: 700
⤷ Tub Depth
: Internal: 460 | External: 480
⤷ Colour
: White
⤷ Internal Bottom Length
: 1077
⤷ Internal Bottom Width
: 287
⤷ Internal Top Length
: 1500
⤷ Internal Top Width
: 570
⤷ Height of Rim
: 25
⤷ Distance Tub edge to centre of drain hole
: 303

⤷ Distance Top edge to centre of overflow hole
: 97
⤷ Diameter of Drain hole
: 52
⤷ Rim Width
: 65 | 50
⤷ Weight in kg
: 32
⤷ Shape
: Rectangular
⤷ Capacity in litres
: 225
⤷ Country of Origin
: Germany
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Acrylic
⤷ No. of Bathers
: 1
⤷ Theme
: Modern
⤷ Bath Therapy Type
: Air-System | Jet System | Combi-System E
⤷ Number of Jets
: 6 | 12 | 24
⤷ Controls
: Yes
⤷ Barcode
: 4067116074260

Additional Info & Downloads

Download the Installation Instructions Pdf File Download the Customer Datasheet Pdf File

Technical Images

Duravit Qatego Single Ended Built In Sanitary Acrylic Whirlpool Bath

£2136.00

RRP: ~~£2870.40~~

STOCK AVAILABLITY: 3-4 Weeks Approx

QS Supplies

Product Variations Info & MFC Code

Size	Air-System	Jet-System	Combi-System E	Capacity (Ltr)
	Weight (Kg)	Weight (Kg)	Weight (Kg)
1600 x 700mm	33.5	37.5	53.5	225
1500 x 750mm	32	36	52	215
1700 x 700mm	35.5	39.5	55.5	240
1700 x 750mm	36.5	40.5	56.5	250
1800 x 800mm	38	42	58	300

2 Features Included In This Product Explained

With / Without Overflow

An overflow is a small hole or opening at the upper part of a sink, basin, bidet or tub that drains away water upon reaching its level so that no water is spilt. When a basin or bath does not come with this design feature, it is called 'without-overflow' and will need a compatible drain.

Jet-System

Jet systems can provide relaxing sensations while you’re in the bath, and you can direct them for a massage-like experience. They raise the airflow’s velocity, providing more pressure from the bubbles, and since we most likely bathe using hot or warm water, the percussive action of the air system’s bubbles gives the muscles a relaxing and soothing experience.
