Jaquar Queens Prime 2-Handle Concealed Thermostatic Shower Valve

Jaquar Queens Prime QQP-CHR-7681KPM Details

Jaquar Queens Prime 2-Handle Concealed Thermostatic Shower Valve.

Available in 2 variants: 2-Outlet, 3-Outlet
Wall-mounted installation
Backplate Size [mm]: 105mm x 290mm [Width x Height]
Backplate Size [cm]: 10.5cm x 29cm [Width x Height]
Connections: 3/4-Inch BSP
Supplied with in-wall part
Cartridges made of high-performance thermostatic polymer materials that meet the global standards for high and low-pressure
Standard temperature range: 15°C to 60°C (59-104˚F)
Shower mixer contains ceramic cartridge for diverting water to the outlets
Protected against backflow
Recommended water pressure: 0.2 bar - 5 bar
Flow rate for 2-outlet valve: 42 lpm @ 3 bar
Flow rate for 3-outlet valve: 52 lpm @ 3 bar
Refer to the technical drawing for more size details

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Queens Prime
⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 10 Years
⤷ Material
: Brass
⤷ Theme
: Traditional
⤷ Installation Type
: Wall Mounted
⤷ Inlet Connections
: 3/4-Inch
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Handle Style
: Crosshead Handle
⤷ Temperature Control
: Thermostatic
⤷ Backplate Width
: 105
⤷ Backplate Height
: 290

⤷ Number of Handles
: 2
⤷ Number of Outlet
: 2, 2
⤷ Outlet Connection
: 3/4-Inch
⤷ Diverter Included
: Yes
⤷ Orientation
: Portrait
⤷ Barcode
: 5057199978691
⤷ Product Type
: Thermostatic Shower Valve
⤷ Plumbing Option
: Concealed
⤷ Maximum Operating Pressure (Bar)
: 5
⤷ Concealed Body Included
: Yes
⤷ Cartridge Included
: Yes

Jaquar Queens Prime 2-Handle Concealed Thermostatic Shower Valve

£354.47

RRP: ~~£479.00~~

STOCK AVAILABLITY: 3-4 Working Days Approx

QS Supplies

1 Features Included In This Product Explained

2-Outlet

The dual outlet Valve comes with a connection for two outlets, so you can use two different fixtures one at a time, such as using the showerhead and shower handset. These Dual outlet shower valves come in various styles and can be used with varying shower fittings. Some come with diverters for switching between the two outlets.

Jaquar Queens Prime 2-Handle Concealed Thermostatic Shower Valve

MFC Code: QQP-CHR-7681KPM|ALD-CHR-681E
