Bristan Appeal Eco Start Basin Mixer Tap With Clicker Waste

Appeal APL ES BAS C Details

Bristan Appeal Eco Start Basin Mixer Tap With Clicker Waste

Size In [mm]: 55mm x 145mm x 170mm [Width x Depth x Height]
Size In [cm]: 5.5cm x 14.5cm x 17cm [Width x Depth x Height]
Base to spout: 105mm [10.5cm]
Centre of inlet to centre of outlet: 110mm [11cm]
Installation type: Deck mounted
Handle type: Paddle lever
Connection inlet: 1/2 Inch BSP flexible tails
Connection outlet: Housed 5lpm M24 aerator
Number of tap holes: 1
Flow type: Single
Suitable for medium and high water pressure systems
Required minimum 0.5 bar to maximum 5.0 bar water pressure
Maximum hot water temperature: 60°C
Maximum static pressure: 10 bar
Cartridge type: 35mm cold start upper seal cartridge
Supplied with flexible tails and clicker waste
Suitable for all plumbing systems
Long-life ceramic cartridge for added durability and smooth control
Eco Start technology saves energy by having cold water as the default central start position of the tap handle
Hot water is only activated when the tap lever is moved from the central position, so your boiler is not unnecessarily fired up
Tap features a flow regulator, which limits the flow of water to 5 litres per minute, reducing the amount of water you use
Refer to the technical diagram for complete technical dimensions
Download the product data-sheet and installation instructions from our additional info section

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Appeal
⤷ Water Activation
: By Lifting / Tilting
⤷ Tap Body Shape
: Round
⤷ Handle Position
: Upwards
⤷ Colour
: Chrome, Brushed Brass, Black
⤷ Warranty/Guarantee
: 10
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 1
⤷ Spout type
: Fixed
⤷ Valve/Cartridge Type
: 35mm Cold Start Upper Seal Cartridge

⤷ Base To Spout
: 105
⤷ Spout Reach
: 110
⤷ Overall Height
: 170
⤷ Width
: 55
⤷ Inlet Connections
: 1/2 Inch BSP Flexible Tails
⤷ Minimum Operating Pressure (Bar)
: 0.5
⤷ Waste Type
: Clicker Waste
⤷ Handle Style
: Lever
⤷ WRAS Approved
: Yes
⤷ Waste Included
: Yes
⤷ Barcode
: 5014868074917
⤷ Product Type
: Basin Mixer Tap

Additional Info & Downloads

Download the Product Data Sheet Pdf File Download the Installation Instructions Pdf File

Bristan Appeal Eco Start Basin Mixer Tap With Clicker Waste

£79.63

RRP: ~~£145.00~~

IN-STOCK

Delivery in 4 Working Days Approx.

QS Supplies

11 Features Included In This Product Explained

Luminance Chrome

It is a hard-wearing chrome plating which is salt-tested and scratch-proof for durable, long-lasting use.

Precise Glide

It comes incorporated with ceramic cartridges for long life with precise control for smooth, leak-free use.

Secure Fix

The design features metal fixings that secure your tap, preventing any movement or rotation during use.

Medium Water Pressure

Water systems operating at a pressure between 0.5 and 0.9 bar are considered medium pressure. Products usually come labelled if they are suitable for use in medium pressure.

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Click-Clack Waste

Also called the Push button or Sprung waste, this waste needs a push down on the stopper to close and a click to open it back again. It is the most commonly used waste due to the ease of its operation.

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
Read more...

Flexible Tail Pipes

Flexible Tails, or "Flexi" Tails, are one of the easiest methods to connect the plumbing pipework to the tap fitting. Mixers generally have two tails, one for the hot water supply and the other for the cold. These tailpipes consist of rubber inside a braided metal and come in many sizes.

Flow Regulator

As the name suggests, a flow regulator is a simple device designed to regulate water flow to a predetermined level. The job of a flow regulator is to stop water wastage. For instance, if the regular flow rate through a tap is 20 litres per minute, a flow regulator can reduce the flow rate between 6 to 12 litres per minute to complete the desired chore without feeling low pressure.

Single Lever Taps

These taps are designed with a single lever or handle to control the water's temperature and flow. Extremely easy to operate, these also allow you to preset the water temperature by leaving it in the position with your preferred water temperature. Besides, it is simple to control the flow of water; the higher you lift the lever or move it to the end, the stronger the water flow.

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws.
