Reina Ottone 600mm Wide Steel Towel Rail Brushed Brass

Reina Ottone RND-OTO080060B Details

Reina Ottone 600mm Wide Steel Towel Rail Brushed Brass.

Key Features

✔It comes in a brushed brass finish
✔Manufactured using steel material
✔Supplied with Brackets, Air vent and End plug
✔EN 442 compliant product
✔Five-year guarantee from Reina against manufacturing defects

Available heights: 800mm, 1200mm and 1600mm - [Optional]
Variants available: Central heating, Dual Fuel and Electric - [Optional]
Heating element type: Standard, On/Off Touch, Thermostatic: LST Mini Round, Mini Round, Touch, LST Weekly and Weekly - [Optional]
Straight towel rail
Width: 600mm (60cm)
Pipe centres: 555mm (45.5cm)
Wall to pipe centres: 59mm-69mm (5.9cm-6.9cm)
Wall distance: 74mm-84mm (7.4cm-8.4cm)
Valves, Sleeving kit and chrome pipe kit [Optional]
For Central Heating And Dual fuel, Radiator valves are highly recommended
Refer to Compatible Valves available in the product
For the Dual Fuel and Electric model, Heating Elements are highly recommended in combination with T-Piece
For Electric models, Optional Liquid Filling is required with the heating element
For BTU, Watts and other details, please refer to the chart in the PRODUCT VARIATIONS INFO and MFC CODE Tab
Download the Installation Guide PDF File from the Additional Info Section
Refer to the technical drawing for more details
The valve shown in the image is not included

Please Note: The appropriate wattage of the element if selected will be decided by the manufacturer, once the order is placed.

Radiator Calculator

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Ottone
⤷ Colour
: Brushed Brass
⤷ Country of Origin
: Turkey
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Steel
⤷ Theme
: Modern
⤷ Installation Type
: Wall-Mounted
⤷ Projection (Depth)
: 74-84
⤷ Width
: 600
⤷ Height
: 800 | 1200 | 1600
⤷ Fixings included
: Yes
⤷ Orientation
: Vertical

⤷ Compliance/Approvals/Standard
: EN 442 Compliant
⤷ Barcode
: 8800161299105
⤷ BTU Output
: 70°C: 800-1253 | 1200-1795 | 1600-2371
⤷ Watts
: 800: 367 | 1200: 526 | 1600: 695
⤷ Tapping / Pipe Centres
: 555
⤷ Valves Included
: Sold Separately
⤷ Fuel Type
: Central Heating | Dual Fuel | Electric
⤷ Wall to Centre of Inlet
: 59-69
⤷ Heating Element Included
: Sold Separately
⤷ Element Type
: Standard | Thermostatic | Digital
⤷ Brackets Included
: Yes

Additional Info & Downloads

Download the Installation Guide Pdf File

Technical Images

Reina Ottone 600mm Width Steel Towel Rail Brushed Brass

Add-Ons

Optional Accessories

Reina provides optional accessories that you may require for the installation. The manufacturer highly recommends these Accessories. Please Note: The image shown is for illustration purpose only.

No Option Selected
OP-113634 - 200mm Chrome Pipe Kit + £16.40

£270.00

RRP: ~~£310.80~~

STOCK AVAILABLITY: 5-7 Working Days Approx

QS Supplies

Product Variations Info & MFC Code

Height:	800mm	1200mm	1600mm
Pipe Centres:	555mm	555mm	555mm
Wall To Pipe Centres:	59-69mm	59-69mm	59-69mm
Wall Distance:	74-84mm	74-84mm	74-84mm
Tube Quantity:	12	18	24
Total Gap:	2	3	4
Watts:	367	526	695
BTU @ 70 Degree:	1253	1795	2371
BTU @ 60 Degree:	1027	1471	1943
BTU @ 50 Degree:	808	1158	1530
BTU @ 45 Degree:	704	1008	1332
BTU @ 40 Degree:	608	871	1151
BTU @ 35 Degree:	509	730	964
BTU @ 30 Degree:	414	592	783
BTU @ 25 Degree:	161	231	305

4 Features Included In This Product Explained

BTU Output

It is the short form of a British thermal unit (BTU or Btu) and is defined as the amount of heat required to raise the temperature of one pound of water by one degree Fahrenheit. It is a standard unit against which radiator efficiency is measured.
Read more...

Optional Sleeving Kit

A sleeving kit in a radiator heating system are components or materials used to sleeve or insulate the pipes or tubes that circulate hot water or steam from the central heating source to the radiators or heating units. The sleeving kit provides thermal insulation and prevents heat loss, adding to the heating systems efficiency.

Optional: Dual Fuel

These radiators or towel warmers can run on a conventional gas-powered central heating system or via your mains electrical supply. You can choose whether or not you want your radiator or towel warmer to come on independently of your central heating system, which is especially useful in summer. These radiators are compatible with heating and hot water, whether the system is open (direct) or closed (indirect).

Optional: Radiator Valve

Radiator valves help control how much hot water enters and leave it, and the flow of water controls how much heat the radiator generates. These are usually found at the radiator's bottom left, and right corners, where the water pipes enter and exit, or can also be present at the bottom near the centre.
Read more...
