Bristan Orta Eco 6 Chrome Bath Shower Mixer Tap

Orta OR BSM E6 C Details

Manufacturing code of this product: OR BSM E6 C
It comes in a chrome finish
Chrome plated to BS EN 248
Includes: Rub clean handset, 1.75m hose and wall bracket
Size In [mm]: 230mm x 145mm x 123mm [Width x Depth x Height]
Size In [cm]: 23cm x 14.5cm x 12.3cm [Width x Depth x Height]
Height of handset: 237mm [23.7cm]
Base to spout: 46mm [4.6cm]
Centre of inlet to centre of outlet: 110mm [11cm]
Flow type: Single
Number of tap holes: 2
Handle type: Lever handle
Installation type: Deck mounted
Manufactured using brass material
Connection inlet: 3/4 Inch BSP threaded tails
Connection outlet: Flow straightener
Maximum hot water temperature: 65°C
Maximum static pressure: 10 bar
Valve type: 3/4 Inch Ceramic Disc Valve - 1/4 turn
Suitable for all plumbing systems
Suitable for low and high water pressure systems
Required minimum 0.2 bar to maximum 5.0 bar water pressure
Supplied with either a 6 or 8-litre-per-minute flow regulator, which can be fitted to the shower hose outlet to reduce water consumption and increase water efficiency (Flow Regulator accurate +/- 10%)
Refer to the technical diagram for complete technical dimensions
Download the product data sheet and installation instructions from our additional info section

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Material
: Brass
⤷ Base To Spout
: 46
⤷ Spout Reach
: 110

⤷ Overall Height
: 123
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Handle Style
: Lever

Additional Info & Downloads

Download the Product Data Sheet Pdf File Download the Installation Instructions Pdf File

Bristan Orta Eco 6 Chrome Bath Shower Mixer Tap

£144.35

RRP: ~~£276.04~~

STOCK AVAILABLITY: 5-7 Working Days Approx

QS Supplies

4 Features Included In This Product Explained

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Flow Straightener

A flow straightener, also called Honeycomb, is a fitting which directs the flow of water from the outlet in a way as to straighten the stream. They are generally not flow-regulated and differ in design from the pressure-compensating aerator.

Flow Regulator

As the name suggests, a flow regulator is a simple device designed to regulate water flow to a predetermined level. The job of a flow regulator is to stop water wastage. For instance, if the regular flow rate through a tap is 20 litres per minute, a flow regulator can reduce the flow rate between 6 to 12 litres per minute to complete the desired chore without feeling low pressure.
