Bristan Prism Brushed Brass Concealed Dual Control Thermostatic Shower Pack

Prism PRISM BB SHWR PK Details

Manufacturing code of this product: PRISM BB SHWR PK
Pack includes: Shower valve with integral two outlet diverter, slimline 200mm round drench head with shower arm, and shower kit with an adjustable riser rail plus a multi-function handset and wall outlet
Height of riser rail: 730mm [73cm]
Length of shower arm: 370mm [37cm]
Size of showerhead: Ø200mm [20cm]
Size of handset: 95mm [9.5cm] x 230mm [23cm] [Width x Height]
Size of back plate: 165mm [16.5cm] x 225mm [22.5cm] [Width x Height]
No of controls: 2
Check valve included: Yes
Shower type: Dual control
Shower kit: Fixed head and adjustable riser kit
Connection inlet: 15mm Compression
Connection outlet: G 1/2 Inch
Maximum hot water temperature: 65°C
Maximum static pressure: 10 bar
Valve type: Thermostatic cartridge and 40mm single lever cartridge
Suitable for all plumbing systems
Suitable for low and high water pressure systems
Fitting depth, including plasterboard and tiles: 50mm - 75mm
The cartridge can be accessed from the front for easy servicing
Dual control: Flow and temp are operated separately giving accurate control of both
Multi-function rub clean handset and drench head: Easily remove limescale and debris by rubbing a finger or cloth over the nozzles
Slim design recessed shower valve will fit into a cavity space as small as 35mm for hassle-free installation
Required minimum 0.2 bar to maximum 5.0 bar water pressure
Refer to the technical diagram for complete technical dimensions
Download the product data sheet and installation instructions from our additional info section

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Brass And ABS
⤷ Theme
: Modern
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Thermostatic Cartridge And 40mm Single Lever Cartridge
⤷ Inlet Centres
: 150
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Hose Included
: Yes
⤷ Hose Length
: 1750
⤷ Height
: 730
⤷ Temperature Control
: Thermostatic
⤷ Backplate Width
: 165

⤷ Backplate Height
: 225
⤷ Diverter Included
: Yes
⤷ Product Type
: Thermostatic Shower Set
⤷ Showerhead Type
: Fixed
⤷ Showerhead Finish
: Brushed Brass
⤷ Riser Rail & Kit Finish
: Brushed Brass
⤷ Handset Included
: Yes
⤷ Valve Size
: 165 W x 255 H
⤷ Shower Head Included
: Yes
⤷ Shower Head Size
: Ø200
⤷ Hose Retainer Included
: Yes
⤷ Outlet Elbow Included
: Yes

Additional Info & Downloads

Download the Product Data Sheet Pdf File Download the Installation Instructions Pdf File

Bristan Prism Brushed Brass Concealed Dual Control Thermostatic Shower Pack

£391.67

RRP: ~~£749.00~~

IN-STOCK

Delivery in 3 Working Days Approx.

QS Supplies

10 Features Included In This Product Explained

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Diverter

A diverter, specifically in bath-shower combos, redirects the water flow from the bathtub spout to the showerhead. You can activate it using the nozzle in the bath shower mixer tap.
Read more...

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

ABS Plastic

ABS, or Acrylonitrile butadiene styrene, is a thermoplastic polymer used to manufacture many non-food products. It is inexpensive and can be easily shaped and machined. It also features high strength, stiffness, increased chemical and temperature resistance, electrical insulation and a glossy look.

2-Outlet

The dual outlet Valve comes with a connection for two outlets, so you can use two different fixtures one at a time, such as using the showerhead and shower handset. These Dual outlet shower valves come in various styles and can be used with varying shower fittings. Some come with diverters for switching between the two outlets.

Family Safe

This feature corresponds with the Thermostatic mechanism and automatic safety stops, preventing running water from getting either too hot or too cold.

Drenching

Drenching in Bristan showers means these showers soak you thoroughly, giving you the most indulgent showering experience.

Rub Clean

Any limescale deposits can simply be wiped clean with a clean cloth - no need to scrub or use harsh cleaners.

2 Outlets 1 On

There are two outlet connections, of which only one can be used at a given time.
