Nuie Binsey Wall-Mounted 2 Tap-Hole Basin Mixer With Plate

Nuie Binsey BIN328 Details

Nuie Binsey Wall-Mounted 2 Tap-Hole Basin Mixer With Plate.

Stunning contemporary curved design
Excellent flow rates, even at low-pressure
Suitable for wall-mounted installation
Size of back-plate: Width 180mm (18cm) x Height 70mm (7cm)
The centre of the inlet to the centre of the outlet is 175mm (17.5cm)
Wall mount cavity: min. 49mm (4.9cm) and max. 62mm (6.2cm)
Inlet centres: 100mm (10cm)
No. of handles: 1
Single lever cartridge type
Cartridge material: Plastic
Pipe size 1/2inch
Suitable for low-pressure water system
Requires 0.2 bar operating water pressure
Flow Rate (l/min): 0.1 Bar - 2.8, 0.5 Bar - 7.1, 1 Bar - 10.2, 2 Bar - 14.8, 3 Bar - 18.3
Technical drawing available for more technical details
Download the Customer Data Sheet and Installation Instruction PDF File from the Additional Info Section

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Lifting | Tilting
⤷ Range
: Binsey
⤷ Handle Position
: Right
⤷ Colour
: Chrome | Matt Black | Brushed Pewter | Brushed Brass | Brushed Bronze
⤷ Warranty/Guarantee
: Chrome: 5 Years | Other Finishes: 3 Years
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Installation Type
: Wall-Mounted
⤷ No. of Holes Required
: 1
⤷ Valve/Cartridge Type
: Single Lever Cartridge

⤷ Spout Reach
: 175
⤷ Inlet Centres
: 100
⤷ Overall Height
: 107.5
⤷ Width
: 180
⤷ Min-Max Wall Mount
: Min. 49 - Max. 61
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Flow Rates (l/min)
: 0.1 Bar: 2.8, 0.5 Bar: 7.1, 1.0 Bar: 10.2, 2.0 Bar: 14.8, 3 Bar: 18.3
⤷ Handle Style
: Lever
⤷ Barcode
: 5056211898818
⤷ Product Type
: Basin Mixer Tap

Additional Info & Downloads

Download the Customer Data Sheet Pdf File Download the Installation Instructions Pdf File

Nuie Binsey Wall-Mounted 2 Tap-Hole Basin Mixer With Plate

£86.53

RRP: ~~£255.00~~

IN-STOCK

Delivery in 3 Working Days Approx.

QS Supplies

4 Features Included In This Product Explained

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

Single Lever Taps

These taps are designed with a single lever or handle to control the water's temperature and flow. Extremely easy to operate, these also allow you to preset the water temperature by leaving it in the position with your preferred water temperature. Besides, it is simple to control the flow of water; the higher you lift the lever or move it to the end, the stronger the water flow.

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
