Kaldewei Avantgarde Asymmetric Duo 1800mm Steel Bath White

Kaldewei Asymmetric 274200010001 Details

Kaldewei Asymmetric Duo 742 Steel Bath is irresistible in its out-of-the-box concept. Crafted innovatively for easy installation, it is acid-resistant and comes with a White finish. Whats more, it is resistant to all cosmetic and medical bath additives and perfumes that are tolerated by human skin. Enameled waste cover and overflow knob are integrated with the design.

It comes with two backrests and a centrally positioned waste and can be availed optionally with an Easy Clean finish for effort-free maintenance. Compatible front and end bath panels can be purchased separately from our online store.

Key Features

✔Bathtub with a comfort zone
✔Features two identical backrests slope and centrally positioned waste hole
✔A generously sized storage area that can also be used as a sit or to accommodate
✔Enamelled waste cover and overflow knob integrated into the design
✔Exciting contrast between the clear lines of the bath rim and the flowing, ergonomic design language of the interior

Size [mm]: 1800mm x 900mm x 400mm [Length x Width x Depth]
Size [cm]: 180cm x 90cm x 40cm [Length x Width x Depth]
Bath available as Standard or with EasyClean coating [Optional]
Can be used with Semi Anti-slip and Full Anti-slip for more protection [Optional]
Comes Without Grip and With Grip[Optional]
Bath available without tap hole or with 2 Tap Hole [Optional]
Bath Grip [Optional]
70 litres displacement on average
Weight: 50kg
Bath rim tap fittings
The image shown is for illustration purposes only
Made of steel enamel
Finish white
For grip hole bath only - One-sided drilling for grip
Bath waste [Optional]
Leg Set Required, Please order adjustable feet set 5030 [Optional]
Refer to the technical drawing for more technical specifications
Thirty years guarantee from Kaldewei against manufacturing defects
Waste, Overflow and Grip shown in the image are not included

Please Note: Bath variants may be special order and delivery lead time may vary.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Bath Type
: Double-Ended
⤷ Range
: Asymetric Duo
⤷ Position of Drain
: Centered Waste
⤷ Interior Shape
: Rounded Rectangular
⤷ Coating
: EasyClean - Sold Separately
⤷ External Length
: 1800
⤷ External Width
: 900
⤷ Tub Depth
: External - 425
⤷ Feets Included
: Sold Separately
⤷ Height Including Feet or Panel
: 540-560
⤷ Front Panel Included
: No
⤷ End Panel Included
: No
⤷ Colour
: White
⤷ Grips Included
: Sold Separately
⤷ Internal Bottom Length
: 1348
⤷ Internal Bottom Width
: 600
⤷ Internal Top Length
: 1670
⤷ Internal Top Width
: 681
⤷ Height of Rim
: 32
⤷ Distance Tub edge to centre of drain hole
: 900

⤷ Distance Top edge to centre of overflow hole
: 70
⤷ Diameter of overflow hole
: 52
⤷ Diameter of Drain hole
: 52
⤷ Distance foot end of tub edge to center of foot
: 580
⤷ Distance between the feet
: 640
⤷ Distance tub edge (foot end) to where handle start
: 753
⤷ Distance tub edge (Foot end) to where handle end
: 1048
⤷ Rim Width
: 62 65
⤷ Distance Between Centre Holes
: 335
⤷ Weight in kg
: 51.5
⤷ Slip Resistant
: No
⤷ Shape
: Rectangular
⤷ Capacity in litres
: 163
⤷ Country of Origin
: Denmark
⤷ Warranty/Guarantee
: 30 Years
⤷ Material
: Steel
⤷ No. of Bathers
: 2
⤷ Waste Included
: Sold Separately
⤷ Tap Holes
: Un-drilled
⤷ Barcode
: 4001112784846

Technical Images

Kaldewei Avantgarde Asymmetric Duo 1800mm Double Ended Steel Bath White

Add-Ons

Bath Leg Set 5037

Installing a bathtub is particularly quick and straightforward with the all-around bathtub base frame model 5037 by Kaldewei. The bath feet positions on the external points of the base of the bathtub guarantee optimum stability.

No Option Selected
OP-29713 - Leg Set 5037 RECOMMENDED
+ £53.71

Optional Bath Waste

Comfort-level and Comfort-level plus can be used to increase the immersion depth by up to 50 mm – just turn the discreet knob. Comfort-level plus knob comes in combination of variable overflow, drain and inlet for filling the bathtub.

No Option Selected
OP-29580 - Comfort Level + £179.38
OP-29581 - Comfort Level Plus + £433.44

£1120.63

RRP: ~~£2114.40~~

STOCK AVAILABLITY: 6 Working Days Approx

QS Supplies

10 Features Included In This Product Explained

Heat Resistant

The surface will not show any burn or smoke marks when hot objects are in contact.

Scratch And Impact Resistant

KALDEWEI steel enamel combines steel and glass, making it durable and greatly resisting mechanical stress. Its resilience is greater than standard material as it is tougher than Acrylic.

Easy To Clean & Hygienic

The surfaces of KALDEWEI steel enamel will not allow dirt and bacteria to gather, making it extremely hygienic and easy to clean.

UV Resistant

KALDEWEI steel enamel has unique properties that help the product retain its original colour for a long time; it does not fade or turn yellow.

100% Sustainable

All products made using special KALDEWEI steel enamel are entirely recyclable as their source is natural raw materials, i.e. glass and steel.

Chemical Resistant

Most detergents, cosmetics, perfumes, bath salts, oils and other additives or general-purpose household cleaning agents cannot damage the KALDEWEI steel enamel.

Beautiful Shape Forever

The durable KALDEWEI steel enamel remains unaffected by changes in temperature and, therefore, will not suffer cracks or moisture damage.

Optional: EasyClean Finish

KALDEWEI EASY-CLEAN FINISH can be opted for so that the water will roll off the surface of the bathtub, sweeping away all dirt and lime particles along

Optional: Full Or Semi Anti-Slip Enamel

KALDEWEI full or Semi anti-slip system comes certified with the German technical inspection association TUV Rhineland for full anti-slip properties compliant with quality class B for wet barefoot areas (DIN 51097) and quality class R 10 for full anti-slip characteristics within working or work areas with enhanced slipping risk (DIN 51130).

Steel Enamel

Steel enamel is a mixture of steel and glass - natural materials with unique properties. It harnesses the strengths of both materials and is hard-wearing enough for bathtubs, showers and basin surfaces, as it protects the surface and retains its value over the decades.

Questions & Answers

Submit Your Questions 2 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Amandine Asked :
Hi, which pre-drilled 2 tap holes, what is the exact location of the holes? Thank you

Answered By QS Team

The Asymmetric Duo can have special drilling applied for 2 tap holes on the wider rim at an extra charge of RRP £94.50; you can choose the tap holes' preferred location and confirm this possible.

Was this answer helpful?

Sophie Asked :
Hello, I ordered this bath last year. I was wondering if I might get some information on how I access the main drain? I have long hair and am fairly sure it needs unblocking :-/ If you could provide some information, it would be appreciated. Many thanks Sophie

Answered By QS Team

To remove any hair that may be clogging up the waste, you can remove the enamel cover using the small suction tool supplied in the waste and overflow kit; the hair would be visible under the cover.

Was this answer helpful?
