Heritage Glastonbury Bath Pillar Taps With Lever Handle

Heritage Glastonbury TGRC01 Details

This beautifully crafted Bath Pillar Tap is finished in chrome from the Glastonbury range designed by Heritage Bathrooms. Formed from a perfect metal into a heritage design, the curving wonder features a bold design with lever handles that makes maximum impact. With a chrome-plated look, these traditional taps are part of the Glastonbury family, designed by creative heads for Heritage. This most affordable pair will impress with delicate design lines with traditional elements. You can get this in 4 finishes white lever, chrome with midnight blue, vintage gold with a white lever, brushed nickel with a white lever.

Features quarter turn 3/4 inch ceramic disc valve
Traditional design
Size [mm]: 140mm x 145mm [Depth x Height]
Size [cm]: 14cm x 14.5cm [Depth x Height]
Inlet connections: G 3/4 inch BSP
The maximum hot water temperature is 65 degrees C
The minimum water pressure recommended for smooth working is 0.2 bar [LP-Low Pressure], and the maximum is 5.0 bar
Plumbing system suitability: all - ideally balanced
The image shown is for illustration purposes only
Download the Installation Instruction Manual PDF File from the Additional Info Section

Info / Size (mm)

Tap
Pipe Centre: 100 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Rotating
⤷ Range
: Glastonbury
⤷ Tap Body Shape
: Round
⤷ Handle Position
: Upwards
⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 10 Years
⤷ Material
: Brass
⤷ Theme
: Traditional
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 2
⤷ Spout type
: Fixed
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Quarter Turn Ceramic Disc

⤷ Handle Material
: Brass
⤷ Base To Spout
: 35
⤷ Spout Reach
: 140
⤷ Overall Height
: 145
⤷ Width
: 55
⤷ Inlet Connections
: G 3/4” BSP
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Flow Rates (l/min)
: 0.1 Bar - 12.8 / 0.5 Bar - 28.3 / 1 Bar - 40.2 / 2 Bar - 56.9 / 3 Bar - 69.6 / 5 Bar - 90.1
⤷ Handle Style
: Stick
⤷ Deck Mount Drill Hole Diameter
: 55
⤷ Barcode
: 5055138555118
⤷ Product Type
: Bath Pillar Tap

Additional Info & Downloads

Download the Product Data Sheet Pdf File Download the Installation Instruction Pdf File Download the Spares Drawings Pdf File

Heritage Glastonbury Bath Pillar Taps With Lever Handle

£112.84

RRP: ~~£188.00~~

IN-STOCK

Delivery in 4 Working Days Approx.

QS Supplies

4 Features Included In This Product Explained

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws.
Read more...

Quarter Turn

Operating these taps is almost effortless; it can be turned on and off by rotating the lever at 90 degrees. These taps have such low friction that they are perfect for people with arthritis, weak grip, the elderly and the young.
