Vado Notion Vertical 3 Outlet Concealed Chrome Thermostatic Valve

Vado Notion TAB-128/3-NOT-C/P Details

The Vado Notion Vertical 3 Outlet Concealed Thermostatic Valve will captivate you instantly with its clean, symmetrical look that not only blends with all styles of decor but has an ageless design that exudes ongoing elegance. The valve comes with easy-to-operate soft-turn handles and features an All-flow function that delivers water to either outlet independently or all outlets simultaneously. Made from high-grade materials and plated in chrome, it is powered by thermostatic and diverter cartridges and features efficient and fast-acting in-built safety features.

Available in 2 variants: Vertical, Horizontal
Concealed 3 outlets 3 handles thermostatic shower valve with 'all-flow' function
Chrome finish
All-flow function - delivers water to either outlet independently or all outlets simultaneously
Wall-mounted installation
Luxury soft-turn handles
Exceptional safety from temperature fluctuations
Minimum operating pressure required: 0.2 bar [LP-Low Pressure] for shower and 1.0 bar [HP-High Pressure] for bath
Excellent flow rates, even at low pressure
It comes with a vertical rectangular back-plate
2 x 3/4 inch female inlets
2 x 3/4 inch female outlets
Includes fitting for 1/2 inch and 3/4 inch pipework
Features limescale-resistant new polymer thermostatic and diverter cartridge
Supplied with mortar guard complete with markings to aid installation and tiling
A flat back valve body allows for a solid, secure mount
Handles have multiple fitting positions to enable perfect alignment of the handle and shroud
25mm (2.5cm) fitting depth tolerance: 75-100mm (7.5cm - 10cm) [minimum - maximum]
Can fit into a 50mm (5cm) stud wall when using an optional studfast bracket [See Option]
Screw-on shrouds and slide-on plates ensure a rapid and simple second fix
Easy-access isolation points
Plate size allows for a 10mm (1cm) tile-cutting tolerance
Optimum installation depth: 88mm (8.8cm) for standard installation
Fifteen years of guarantee from the manufacturer
For complete size details, please refer to the technical drawing
Download the Installation And Care Instruction PDF File from the Additional Info Section

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Shape
: Rectangular
⤷ Warranty/Guarantee
: 15 Years
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Overall Height
: 250
⤷ Min-Max Wall Mount
: 75-100
⤷ Inlet Connections
: 3/4-Inch
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Handle Style
: Knob Handle

⤷ Temperature Control
: Thermostatic
⤷ Backplate Width
: 80
⤷ Backplate Height
: 250
⤷ Number of Handles
: 3
⤷ Number of Outlet
: 3
⤷ Outlet Connection
: 3/4-Inch
⤷ Plumbing Option
: Concealed
⤷ Cartridge Included
: Yes
⤷ Cartridge Type
: Thermostatic, Diverter, Flow

Additional Info & Downloads

Download the Installation And Care Instructions Pdf File

Add-Ons

Studfast Brackets

The Studfast is an easy, secure and robust method of mounting thermostatic shower valves into stud walls to create a firm and trouble-free installation. Please Note: The image shown is for illustration purposes only.

No Option Selected
OP-44782 - Studfast Concealed Wall Bracket + £34.49

Videos

Video of Attaching A Shower Valve And Fitting To The Wall Stud

Vado Notion Vertical 3 Outlet Concealed Thermostatic Valve

£545.95

RRP: ~~£895.00~~

STOCK AVAILABLITY: 3 Working Days Approx

QS Supplies

5 Features Included In This Product Explained

Diverter

A diverter, specifically in bath-shower combos, redirects the water flow from the bathtub spout to the showerhead. You can activate it using the nozzle in the bath shower mixer tap.
Read more...

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

All Flow

The All flow function within the shower valves enables the water to flow to either individual shower outlets or all outlets simultaneously.
